• • SPECIFICATION |
• • • • • • • • • •
|
Print Method |
Direct Thermal, Thermal Transfer
|
Print Speed |
SLP-TX400: Up to 7 ips (178 mm/sec), SLP-TX403: Up to 5 ips (127 mm/sec)
|
PRINT RESOLUTION |
SLP-TX400: 203 dpi, SLP-TX403: 300 dpi
|
PRINT WIDTH |
SLP-TX400: Up to 108 mm, SLP-TX403: Up to 105.7 mm
|
PRINT LENGTH |
Up to 1,000 mm
|
SENSOR |
Head open, Reflective (adjustable), Ribbon-End, Transmissive
|
Media Type |
Black Mark, Continuous, Fan-Fold, Gap, Notch
|
Media Width |
25 ~ 112 mm
|
Media Roll Size |
Up to 130 mm
|
Media Thickness |
0.06 ~ 0.20 mm
|
Supply Method |
Easy Paper Loading
|
Inner Core |
25.4 ~ 38.1mm
|
Ribbon Type |
Outside, Resin, Wax, Wax/Resin
|
Ribbon Width |
33 ~ 110 mm
|
Ribbon Length |
Up to 300 m
|
Core Inner Diameter |
25.4 mm, 12.5 mm
|
DIMENSION (W X D X H IN MM) |
214 x 310 x 195 mm
|
Weight |
2.85 kg (6.28 lbs.)
|
Electrical |
50/60Hz, EnergyStar Certified, External Power Adaptor 100-240V AC
|
Memory |
64 MB SDRAM, 128 MB Flash
|
Interface |
• • • • • • • • • •
|
Standard Interface |
SLP-TX400R(RFID) USB + Serial + Ethernet + Bluetooth² / WLAN¹ + RFID, USB + Serial + Parallel
|
Optional Interface |
① USB + Serial + Ethernet + WLAN¹, ② USB + Serial + Ethernet + Bluetooth²
|
WLAN¹ |
802.11a/b/g/n/ac USB dongle type
|
Bluetooth² |
USB dongle type (Optional)
|
Real Time Clock |
Supported
|
• • ENVIRONMENTAL |
• • • • • • • • • •
|
Operating Temperature |
Operating: 0 ~ 40℃ (32 ~ 104℉), Storage: -20 ~ 60℃ (-4 ~ 140℉)
|
Operating Humidity |
Operating: 10 ~ 80% RH, Storage: 10 ~ 90% RH
|
Emulation |
BPL-E™ (EPL), BPL-Z™ (ZPLII), SLCS™
|
Driver / Utility |
Bartender Ultralite for BIXOLON, Label Artist-II™, Linux / Mac CUPS Driver, OPOS Driver, Utility Program, Virtual COM USB / Ethernet Driver, Windows Driver (Europlus / Seagull)
|
SDK / Plugin |
Android / iOS / Windows SDK, Chrome SDK, Linux SDK, Xamarin SDK (Windows, Android only)
|
Browser / App |
Label Artist™ Mobile (Android, iOS), mPrint App (Android, iOS), Windows mPrint Browser (All)
|
• •Fonts/Graphics/Symbologies |
• • • • • • • • • •
|
Fonts |
10 SLCS Resident Bitmap Fonts, 16 BPL-Z™ Resident Bitmap Fonts, 23 Code Page, 5 BPL-E™ Resident Bitmap Fonts, One BPL-Z™ Resident Scalable Font, One SLCS Resident Scalable Font, Unicode supported (UTF-8, UTF-16LE,UTF-16BE)
|
Graphics |
Supporting user-defined fonts, graphics, formats, and logos
|
Barcode Symbologies |
• • • • • • • • • •
|
1D |
Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar (RSS-14), IMB, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, Standard 2-of-5, UPC-A, UPC-E, UPC/EAN extensions
|
2D |
Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39
|
Optional Accessories |
Auto Cutter, External Paper Supply, Peeler, RFID, WLAN Dongle (Consensus required)
|
Frequency |
865 ~ 868MHz(EU), 902 ~ 928MHz(KR, USA, CHN), UHF
|
Transmit Power |
1W
|
Modulation |
ASK
|
Protocol |
UHF EPC Class 1 Gen 2 V1.2/ ISO 18000-6C
|
Auto Cutter |
Optional
|
Tag Pitch |
Min 25mm
|
