STANDARD FEATURES | Dual-wall frame construction, ENERGY STAR qualified, OpenACCESS™ for easy media loading, Single button for feed/pause, Single LED status indicator, Thermal Transfer or Direct Thermal print method, USB connectivity, ZPL and EPL programming languages |
---|
• • Physical Characteristics | • • • • • • • • • • |
---|
Dimensions | Direct Thermal: 8.6 in. L x 6.9 in. W x 5.9 in. H, Thermal Transfer: 10.5 in. L x 7.75 in. W x 7.5 in. H |
---|
Weight | 2.5 lbs./1.1 kg |
---|
• • SPECIFICATION | • • • • • • • • • • |
---|
RESOLUTION | 203 dpi/8 dots per mm |
---|
Memory | 256 MB Flash; 128 MB SDRAM |
---|
Maximum Print Width | 4.09 in./104 mm |
---|
Maximum Print Speed | 4 in./102 mm per second |
---|
Media Sensors | Fixed off-center gap sensor, Movable black mark sensor, limited range from center to left side |
---|
FIRMWARE | EPL 2, XML, ZPL II |
---|
• • Media Characteristics | • • • • • • • • • • |
---|
Maximum Label Length | 39.0 in./991 mm |
---|
Media Width | 1.00 in. / 25.4 mm to 4.4 in. / 112 mm |
---|
Media Roll Size | 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters, 5.00 in./127 mm outer diameter Core inner diameter |
---|
Media Thickness | 0.003 in. (0.08 mm) min, 0.0075 in. (.1905 mm) max. (tear-off mode only) |
---|
Media Type | , die-cut or ccontinuous direct thermal or thermal transfer labels with or without black line, continuous receipt paper, Roll-fed or fan-fed, tag stock, wristbands |
---|
• • RIBBON | • • • • • • • • • • |
---|
Ribbon Outside Diameter | 1.34 in./ 34 mm (74 m) |
---|
Maximum Ribbon Length | 244 ft. (74 m) |
---|
Ribbon Ratio | 1:1 media to ribbon (74 m) |
---|
Ribbon Width | 1.33 in./ 33.8 mm ~ 4.3 in./ 109.2 mm |
---|
Core I.D. | 74 Meter ribbon 0.5 in./ 12.7 mm |
---|
• • OPERATING CHARACTERISTICS | • • • • • • • • • • |
---|
Operating Temperature | 40° to 105° F/4.4° to 41° C |
---|
Storage temperature | -40° to 140° F/-40° to 60° C |
---|
Operating Humidity | 10% to 90% non-condensing |
---|
Storage Humidity | 5% to 95% non-condensing |
---|
Electrical | 50/60Hz, Auto-detectable (PFC Compliant) 100-240VAC, ENERGY STAR qualified |
---|
Options and Accessories | • • • • • • • • • • |
---|
Media Handling | Factory installed peeler |
---|
Real Time Clock | None |
---|
• •Fonts/Graphics/Symbologies | • • • • • • • • • • |
---|
Barcode Ratios | 2:1 and 3:1 |
---|
1D | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, ISBT-128, Logmars, MSI, Planet Code, Plessey, Postnet, Standard 2-of-5, UPC-A, UPC-A and UPC-E with EAN 2 or 5 digit extensions, UPC-E |
---|
2D | Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code |
---|
FONTS AND GRAPHICS | 16 resident expandable ZPL II bitmap fonts, 50 MB user available non-volatile memory, 8 MB user available SDRAM, China units include SimSun simplified Chinese font, Five resident expandable EPL2 fonts, native open-type font support, two resident scalable ZPL fonts, Unicode™ compliant for multi-language, on-demand thermal printing |
---|
PRINTER SUPPLIES | Keep your Zebra printer up and running with genuine Zebra printer supplies, available directly from Zebra. |
---|
BRAND | ZEBRA |
---|
