Kiosk Mercury EK-1600 Series

Posiflex Products

With a sleek and slim deign, the Mercury EK-1600 Series is a 15.6″ display kiosk with a compact footprint that is suitable for retail stores. With varieties of self-service transaction peripherals, the Mercury EK-1600 Series serves as an extension of employees. It can handle mundane tasks while allowing the employee to focus on providing better customer service.

Built to Fit in and Get Down to Your Business
• 15.6” or 21.5” true-flat PCAP touch screen
• Flexible configurations: floor-standing or countertop
• Modular design for easy serviceability
• A good value kiosk in entry-level category
• Popular uses: product display & advertising, ordering & payment, click & collect, ticketing & e-reservations, wayfinding & customer guidance

With a sleek and slim deign, the Mercury EK-1600 Series is a 15.6″ display kiosk with a compact footprint that is suitable for retail stores. With varieties of self-service transaction peripherals, the Mercury EK-1600 Series serves as an extension of employees. It can handle mundane tasks while allowing the employee to focus on providing better customer service.

Built to Fit in and Get Down to Your Business
• 15.6” or 21.5” true-flat PCAP touch screen
• Flexible configurations: floor-standing or countertop
• Modular design for easy serviceability
• A good value kiosk in entry-level category
• Popular uses: product display & advertising, ordering & payment, click & collect, ticketing & e-reservations, wayfinding & customer guidance



• • SPECIFICATION

• • • • • • • • • •

Processor

Dual Cortex-A72 + Quad Cortex-A53

System Memory

DDR4, 2GB

Storage Device

16 GB eMMC

Power Supply

12V/60W x 1 + 24V/60W x 1

OS Support

Android 9.0

SERIAL PORT

RJ50 x 2

STANDARD USB PORT

6, USB 3.0 x 1+USB 2.0 x 5

OTG USB

1 x micro USB

DISPLAY PORT

1 x HDMI

LAN PORT

10/100/1000 Mb x 2

Audio

Internal 3W speaker x 2

• • DISPLAY & TOUCH

• • • • • • • • • •

LCD

15.6"

RESOLUTION

1920 x 1080

TOUCH

True-flat PCAP touch with multi-touch support

• • PHYSICAL DIMENSION

• • • • • • • • • •

DIMENSION (W X D X H IN MM)

Countertop version (Landscape): 395 x 395 x 513, Countertop version (Portrait): 395 x 395 x 646, Floorstanding version (Landscape):500 x 500 x 1420, Floorstanding version (Portrait): 500 x 500 x 1420

Weight

Countertop version: 18.2, Floorstanding version: 30.4

• • ENVIRONMENTAL

• • • • • • • • • •

OPERATING CONDITION

0°C – 50°C, 20%RH – 90%RH

STORAGE CONDITION

-20°C – 70°C, 10%RH – 90%RH

Proximity Sensor

Range from 60 cm to 100 cm

CAMERA

1MP wide angle camera

Built In Printer

3” thermal printer w/auto cutter, 200 mm/sec (max.)

Status Indicator

RGB Color LED Indicator (for portrait mode only)

WIFI

USB WiFi dongle

Scanner

2D barcode scanner

EMV Payment Device Bracket

Custom bracket support for various EMV payment devices

4G COMMUNICATION

Support selected bands & countries with full SIM slot (mini-PCIe module) by request
