• • PHYSICAL CHARACTERISTICS |
• • • • • • • • • • |
Dimensions |
155 mm L x 75.5 mm W x 18.6 mm H, 6.1 in. L x 2.9 in. W x 0.73 in. H |
Weight |
8.8 oz./249 g with battery |
Display |
5.0 in. High Definition (1280 x 720), exceptionally bright, optically bonded to touch panel, outdoor viewable |
Imager Window |
Corning Gorilla Glass |
Touch Panel |
Corning® Gorilla® Glass, Dual mode capacitive touch with stylus or bare or gloved fingertip input (conductive stylus sold separately) |
Backlight |
LED backlight |
Power |
Rechargeable Li-Ion, PowerPrecision+, > 15.48 Watt hours, > 4150 mAh |
EXPANSION SLOT |
User accessible MicroSD up to 32GB SDHC and up to 256 GB SDXC |
SIM Card |
1 nano SIM |
Network Connections |
High Speed (Host and Client), USB 2.0, WLAN, WPAN (Bluetooth), WWAN |
Keypad |
On-screen keypad and enterprise keyboard |
Voice and Audio |
Bluetooth wireless headset support, HD Voice, High quality speaker phone, PTT will support headset and speakerphone mode, speaker, SWB & FB audio, Three microphone support with noise cancellation, vibrate alert |
Button |
dedicated push-to-talk button and volume up/down buttons, dual dedicated scan buttons, Six programmable buttons for maximum flexibility |
• • Performance Characteristics |
• • • • • • • • • • |
CPU |
Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz |
Operating System |
Android 10, upgradebale through A11/R3 |
Memory |
4GB RAM/32GB Flash |
• • USER ENVIRONMENT |
• • • • • • • • • • |
Operating Temperature |
-4°F to 122°F/-20°C to 50°C |
Storage temperature |
-40°F to 158°F/-40°C to 70°C |
Humidity |
5% to 95% non-condensing |
Drop Specification |
Multiple 4 ft/1.2m drops to tile over concrete -10°C to 50°C (14°F to 122°F), Multiple 6 ft. drops to concrete with the rugged boot accessory per Mil STD 810 G |
Sealing |
IP68 and IP65 per applicable IEC sealing specifications |
Vibration |
4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to 2 kHz), 60 minute duration per axis, 3 axis |
Thermal Shock |
-40° F to 158° F/-40° C to 70° C rapid transition |
Electro-Static Discharge |
+/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge |
• •Interactive Sensor Technology (IST) |
• • • • • • • • • • |
Light Sensor |
Automatically adjusts display backlight brightness |
Magnetometer |
eCompass automatically detects direction and orientation |
Motion Sensor |
3-axis Accelerometer with MEMS Gyro |
Pressure Sensor |
Automatically detects altitude information for locating |
Proximity Sensor |
Automatically detects when the user places the handset against head during a phone call to disable display output and touch input |
• • DATA CAPTURE |
• • • • • • • • • • |
Scanning |
Code 39 barcode: 20 Mil: 2.0 in. to 30.0 in./5.08 cm to 76.2 cm 4 Mil: 3.3 in. to 8.8 in./8.4 cm to 22.4 cm, Digimarc support, SE4710 imager (1D and 2D) with extraordinary range: Scan range |
CAMERA |
Front — 5 MP; f/2.0 aperture, Rear — 13 MP autofocus; f/2.2 aperture; flash LED generates balanced white light; supports Torch mode |
NFC |
FeliCa and ISO 15693 cards, ISO 14443 Type A and B, P2P mode and Card Emulation via Host, TC57 Only: Card Emulation via Host and UICC |
• • Wireless WAN Data and Voice Communications |
• • • • • • • • • • |
Radio Frequency Band |
AT&T FirstNet Ready certification, Carrier Aggregation up to 3DL CA, GSM/GPRS/EDGE: 850/900/1800/1900, LTE FDD: 700/800/850/900/1800/1900/AWS/2100/2600 (28,13,14,12,17/19,20/5,26/8/3/2,25/4,66/1/7), LTE TDD: 1900/2300/2500 (39/40/41,38); UMTS/HSPA/HSPA+: 850/900/AWS/1900/2100 (5/8/4/2/1), Supports VoLTE, Verizon PNTM certification |
GPS |
Autonomous, Concurrent GPS, GLONASS; Gallileo; BeiDou, and A-GPS, Supports IZAT™ XTRA |
Multimedia |
Including TSPEC, Wi-Fi Multimedia™ (WMM) and WMM-PS |
• • WIRELESS LAN |
• • • • • • • • • • |
Radio |
5GHz 2×2 MU-MIMO, IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v3/w, IPv4, IPv6, Wi-Fi™ certified |
Data Rates |
2.4GHz: 802.11b/g/n — up to 300 Mbps, 5GHz: 802.11a/n/ac — up to 866.7 Mbps |
Operating Channels |
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency, Channel 1-13 (2412-2472 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, Channel 36-165 (5180-5825 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165, Channel Bandwidth: 20, 40, 80 MHz |
Security and Encryption |
EAP-PWD, EAP-TLS, LEAP, PEAPv0- MSCHAPv2, PEAPv1- EAP-GTC, WEP (40 or 104 bit), WPA/WPA2 Enterprise (TKIP and AES) —EAP-TTLS (PAP, MSCHAP, MSCHAPv2), WPA/WPA2 Personal (TKIP and AES) |
Certifications |
WFA (802.11n, WMM-PS, 801.11ac, PMF) |
Fast Roam |
802.11r, Cisco CCKM, OKC, PMKID caching |
• • WIRELESS PAN |
• • • • • • • • • • |
Bluetooth |
Bluetooth Low Energy (BLE), Bluetooth v5.0, Class 2 |
BRAND |
ZEBRA |
