POS Terminal XT-6515

Posiflex Products

The POS Terminal  XT-6515 Series* is the successor of the XT-5515, which has been enhanced with 6th generation Intel Skylate CPUs, which is powerful enough to handle any task imaginable that comes its way.

The XT-6515 features a 15” true-flat PCAP touch screen, beautifully sculptured slim body, and sexily curved base stand, it looks right at home at any elegantly decorated store. More than just good looks, the XT-6515 offers ample of performance and flexibility to satisfy the most demanding daily POS operations.

ر.ق6.00 for 3 item(s)

The POS Terminal  XT-6515 Series* is the successor of the XT-5515, which has been enhanced with 6th generation Intel Skylate CPUs, which is powerful enough to handle any task imaginable that comes its way.

The XT-6515 features a 15” true-flat PCAP touch screen, beautifully sculptured slim body, and sexily curved base stand, it looks right at home at any elegantly decorated store. More than just good looks, the XT-6515 offers ample of performance and flexibility to satisfy the most demanding daily POS operations.



• • SPECIFICATION

• • • • • • • • • •

Processor

Intel Skylake Core i5-6500TE CPU, up to 3.30 GHz, 6M cache, Intel Skylake Core i7-6700TE CPU, up to 3.40 GHz, 8M cache

System Memory

DDR4 SO-DIMM x 2, max. 32 GB

Storage Device

SATA connectorx 2+ M.2 connector (SATA or PCIe) x 1

Raid Function

YES

Intel VPro Support

YES

TPM

Yes

Power Supply

12V/100W

OS Support

Windows 7/POSReady 7/Windows Embedded 8.1 Industry 64 bit/Windows 10 IoT 64 bit/Linux per request

• • DISPLAY & TOUCH

• • • • • • • • • •

LCD

15" TFT LCD

RESOLUTION

1024 x 768

TOUCH

True-flat PCAP touch with multi-touch support (IP65 on front panel)

• • I/O & EXPANSION

• • • • • • • • • •

SERIAL PORT

6, 4 on I/O plate (DB9 x 2 + RJ50 x 2) + 2 via optional converter cable from service window, 5V support on all COM ports, 12V support on COM1 to 4 (all converter cables are optional)

PARALLEL PORT

1, via optional conversion cable through service window

STANDARD USB PORT

6, USB 3.0 x 4 + USB 2.0 x 2

POWERED USB PORT

Optional 24V x 1 + 12V x 3 via GEN8E base

LAN PORT

10/100/1000 Mb x 2

DISPLAY PORT

VGA x 1, 12V support for Posiflex monitors; HDMI x 1

CR PORT

1, control 2 CR via optional Y-cable

PS/2 PORT

1, via optional conversion cable through service window

UPS PORT

Yes

Audio

Internal 2W speaker x 1 + Line-out

EXPANSION SLOT

M.2 x 1

• • PHYSICAL DIMENSION

• • • • • • • • • •

DIMENSION (W X D X H IN MM)

372 x 320 x 252.7

WEIGHT (N. W. IN KG)

5.86

• • ENVIRONMENTAL

• • • • • • • • • •

OPERATING CONDITION

0°C – 40°C, 20%RH – 90%RH (Equipped with HDD); 0°C – 50°C, 20%RH – 90%RH (Equipped with SSD)

STORAGE CONDITION

-20°C – 70°C, 10%RH – 90%RH

• • BUILT-IN OPTIONS

• • • • • • • • • •

WIFI

M.2 WiFi/BT module

• • ATTACHMENT OPTIONS

• • • • • • • • • •

POS MONITOR

"Non-touch TFT LCD: 7"" (bezel type)/9.7"" (bezel-free/bezel type)/12.1""/14"" (bezel-free)/15"" (bezel-free/bezel type); PCAP touch TFT LCD: 9.7""/14""/15""; Resistive touch TFT LCD: 15"""

LINE DISPLAY

2 x 20 rear-mount VFD/LCD customer line display; 7" color LCD graphical customer line display

PERIPHERALS

MSR; iButton; RFID; Fingerprint Sensor; Price Checker Kit (with wall mount bracket + 2D barcode scanner)
