4-Line Alpha Pager

LRS

This is truly the first Alphanumeric Staff Pager designed with our customers in mind.
LRS 4-Line Alphanumeric Staff Pager is absolutely the easiest to use, on-premise and full-messaging pager on the market. Until now, the complexity of the standard Alphanumeric pager has been overwhelming and not user-friendly. Our 4-Line Alphanumeric Staff Pager has simplified menus and only gives you the on-site features you need such as Auto On/Off, read messages and delete messages. It boasts advanced features such as group paging, out-of-range indication, low battery symbol and wireless programmability.

This is truly the first Alphanumeric Staff Pager designed with our customers in mind.
LRS 4-Line Alphanumeric Staff Pager is absolutely the easiest to use, on-premise and full-messaging pager on the market. Until now, the complexity of the standard Alphanumeric pager has been overwhelming and not user-friendly. Our 4-Line Alphanumeric Staff Pager has simplified menus and only gives you the on-site features you need such as Auto On/Off, read messages and delete messages. It boasts advanced features such as group paging, out-of-range indication, low battery symbol and wireless programmability.



• • SPECIFICATION

• • • • • • • • • •

Operating Environment

Humidity: <95% (non-condensing), Operating temperature range: 0 to 45 degrees Celsius, Transport temperature range: -20 to 60 degrees Celsius

Power

Alkaline 1 x AAA, Battery charger power supply: n/a

Paging Receiver

Antenna: Internal antenna, Frequency Range: 413 MHz – 470 MHz (See ordering information below), Modulation: FSK (Frequency Shift Keying), OTA Baud rate: 512/1200/2400

Supported Paging Protocols

POCSAG

User Interface

3 Push Buttons, Buzzer, LCD display, monochrome, 128×64 dots, Vibration motor

Regulatory Certifications

ANSI C63.4:2009, EC 300 220-1 v2.3.1, EN 301 489-1 v1.9.2:2011, EN 55022:2006 Class B, EN 61000-4-2:2009, EN 61000-4-3:2010, European Community: EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2010, United States and Territories: 47 CFR FCC Part 15 Subpart B (Class B)

Dimensions

2.5 x 1.77 x .75 (height) inches

Weight

0.2 lb

Ordering Information

RX-E4X- 434 (Algeria, Bahrain, Egypt, Jordan, Kuwait, Morocco, Oman, Qatar and Tunisia), RX-E4X- 467 (Cyprus, Iraq, Iran, Lebanon, Libya, Saudi Arabia, Turkey, U.A.E and Yemen)

Frequency Shipped

434.000MHz (Algeria, Bahrain, Egypt, Jordan, Kuwait, Morocco, Oman, Qatar and Tunisia), 467.750MHz (Cyprus, Iraq, Iran, Lebanon, Libya, Saudi Arabia, Turkey, U.A.E and Yemen)
