Flexible and secure card printing with ground-breaking simplicity No matter what type of card you need to print — from identity and access to membership, event and credit/debit cards — the ZC300 will help you do it better, faster and easier. Elegant engineering eliminates virtually all pain points associated with card printing. The result is push-button simplicity no matter what you are printing — single or dual-sided magnetic stripe or contactless cards, in color or black and white. And with a ground-breaking fits-everywhere design, you can get secure card printing wherever you need it.
| Printing Specifications | 140 cards/hour dual-sided YMCKOK, 200 cards/hour single-sided YMCKO, 450 cards/hour dual sided monochrome, 900 cards/hour single sided monochrome, Dye-sublimation thermal transfer direct to card print method, Edge-to-edge printing on standard CR-80 media, Full-color or monochrome printing, Single and dual-sided printing |
|---|---|
| • • OPERATING CHARACTERISTICS | • • • • • • • • • • |
| Operating Temperature | 59º F to 95º F/15º C to 35º C |
| Storage temperature | 23º F to 158º F/-5º C to 70º C |
| Operating Humidity | 20% to 80% non-condensing |
| Media Storage | Humidity: 35% to 65% non-condensing, Temperature: 41º F to 77º F/5º C to 25º C |
| Electrical | Auto-switching single-phase AC power, FCC Class A, Frequency range: 47-63 Hz, Operating range: 90-132VAC and 190-264VAC RMS |
| Dimensions | Dual Sided 10.2 in. H x 6.2 in. W x 18.4 in. D 258 mm H x 157 mm W x 468 mm D, Single Sided 10.2 in. H x 6.2 in. W x 15.1 in. D 258 mm H x 157 mm W x 383 mm D |
| Weight | Dual Sided 9.7 lbs (4.4 kg), Single Sided 8.8 lbs (4.0kg) |
| COMMUNICATION AND INTERFACE CAPABILITIES | 802.11ac (Optional), Built-in 10/100 Ethernet (Optional), USB 2.0 |
| Encoding Options and Specifications | Magnetic stripe encoder — ISO 7811 (new and pre-encoded; tracks 1, 2, and 3; high and low coercivity; stripe down; 30 mil cards only), Third party contactless encoder integration kit (ZIP Pocket) |
| Driver / Utility | MAC OS X 10.13.X (64 bit), Microsoft Windows Certified, Ubuntu 16..X (64 Bit) |
| BRAND |
