• • SPECIFICATION |
• • • • • • • • • • |
Print Method |
Direct Thermal |
Print Speed |
XD5-40d: Up to 7 ips (178 mm/sec), XD5-43d: Up to 5 ips (127 mm/sec) |
PRINT RESOLUTION |
XD5-40d: 203 dpi, XD5-43d: 300 dpi |
PRINT WIDTH |
XD5-40d: Up to 108 mm, XD5-43d: Up to 105.7 mm |
PRINT LENGTH |
Up to 1,000 mm |
SENSOR |
Head open, Reflective (adjustable), Transmissive(Fixed) |
• • Media Characteristics |
• • • • • • • • • • |
Media Type |
Black Mark, Continuous, Fan-Fold, Gap, Notch |
Media Width |
15 ~ 118 mm |
Media Roll Size |
Up to 127 mm |
Media Thickness |
0.06 ~ 0.20 mm |
Supply Method |
Easy Paper Loading |
Inner Core |
25.4 ~ 38.1mm |
• • Physical Characteristics |
• • • • • • • • • • |
DIMENSION (W X D X H IN MM) |
1194 x 248 x 169 mm |
Weight |
1.89kg (4.17 lbs.) |
Electrical |
50/60Hz, EnergyStar Certified, External Power Adaptor 100-240V AC |
Display |
Optional: FSTN LCD (200 x 100 pixels), Standard: None |
Guide |
Combined paper holder and guide + Front paper guides |
• • Performance Characteristics |
• • • • • • • • • • |
Memory |
64 MB SDRAM, 128 MB Flash, Optional: â‘ 64 MB SDRAM, 128 MB Flash â‘¡ 256 MB SDRAM, 256 MB Flash |
Interface |
• • • • • • • • • • |
Standard Interface |
USB2.0 + USB Host |
Optional Interface |
USB2.0 + USB Host + Bluetooth², USB2.0 + USB Host + Serial + Ethernet³, USB2.0 + USB Host + Serial + Ethernet³ + Bluetooth², USB2.0 + USB Host + Serial + Ethernet³+WLAN¹, USB2.0 + USB Host + WLAN¹ |
WLAN¹ |
Built-in type, 802.11a/b/g/n (5GHz and 2.4 GHz) |
Bluetooth² |
Built-in type, V4.2 Classic / LE, Class 1, MFi certified |
Ethernet³ |
10/100Mbps |
Real Time Clock |
Supported |
• • Software |
• • • • • • • • • • |
Emulation |
BPL-Eâ„¢ (EPL), BPL-Zâ„¢ (ZPLII), SLCSâ„¢ |
Driver / Utility |
Bartender Ultralite for BIXOLON, Label Artist-II™, Linux / Mac CUPS Driver, OPOS Driver, SAP® Device Driver, Utility Program, Virtual COM USB / Ethernet Driver, Windows Driver (Europlus / Seagull) |
SDK / Plugin |
Android / iOS / Windows SDK, Chrome SDK, Linux SDK, Xamarin SDK |
Application |
Label Artistâ„¢ Mobile (Android, iOS), mPrint App (iOS), mPrint Server (Windows, iOS) |
MDM |
BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android) |
• •Fonts/Graphics/Symbologies |
• • • • • • • • • • |
Fonts |
10 SLCSâ„¢, 16 BPL-Zâ„¢, 23 Code Page, 5 BPL-Eâ„¢, One BPL-Zâ„¢, One SLCSâ„¢, Unicode supported (UTF-8, UTF-16LE,UTF-16BE) |
Graphics |
Supporting user-defined fonts, graphics, formats, and logos |
Barcode Symbologies |
• • • • • • • • • • |
1D |
Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar (RSS-14), IMB, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, UPC-A, UPC-E, UPC/EAN extensions |
2D |
Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
Optional Accessories |
Auto Cutter, External Paper Supply, Peeler |
BRAND |
BIXOLON |
