| • • SPECIFICATION | • • • • • • • • • • |
|---|
| RESOLUTION | 203 dpi/8 dots per mm |
|---|
| Memory | 8 MB Flash, 8 MB SDRAM (standard) |
|---|
| PRINT WIDTH | 4.09”/104 mm |
|---|
| PRINT LENGTH | 39”/990 mm |
|---|
| Print Speed | 4”/102 mm per second maximum |
|---|
| Media Sensors | Reflective and transmissive sensors |
|---|
| • • Media Characteristics | • • • • • • • • • • |
|---|
| Media Width | 1.00”/25.4 mm to 4.25”/108 mm |
|---|
| Media Length | 0.38”/9.6 mm to 39”/990 mm |
|---|
| Media Roll Size | 5”/127 mm O.D. on a 1.00”/25.4 mm, 1.5”/38 mm I.D. core |
|---|
| Media Thickness | 0.003”/0.075 mm to 0.007”/0.18 mm |
|---|
| Media Type | Label stock (die cut or continous, direct thermal or thermal transfer), Receipt paper (continous, direct thermal), Roll-fed or fan-fed, Tag stock (die cut or continous, direct thermal or thermal transfer), Wristband stock (direct thermal or thermal transfer) |
|---|
| • • RIBBON | • • • • • • • • • • |
|---|
| Ribbon Outside Diameter | 1.34”/34 mm |
|---|
| Ribbon Length | 244’ (74 m) |
|---|
| Ribbon Capacity | 1:1 One ribbon per roll of media |
|---|
| Ribbon Width | 1.33”/33.8 mm to 4.3”/110 mm |
|---|
| Core I.D. | 0.5”/12.7 mm |
|---|
| • • OPERATING CHARACTERISTICS | • • • • • • • • • • |
|---|
| Operating Temperature | 40° F/5° C to 105° F/41° C |
|---|
| Storage temperature | -40° F/-40° C to 140° F/60° C |
|---|
| Operating Humidity | 10% to 90% non-condensing R.H. |
|---|
| Storage Humidity | 5% to 95% non-condensing R.H. |
|---|
| Software | ZebraDesigner, ZebraDesigner Driver, ZebraDesigner™ Pro |
|---|
| FIRMWARE | EPL 2, ZPL II |
|---|
| COMMUNICATION AND INTERFACE CAPABILITIES | Centronics® parallel (36 pin) connector ports, RS-232 Serial interface, USB V1.1 interface, bi-directional |
|---|
| • •Fonts/Graphics/Symbologies | • • • • • • • • • • |
|---|
| Fonts | 16 resident expandable ZPL fonts, One resident scalable ZPL font, resident expandable EPL2 fonts, Supports user-defined fonts and graphics— including custom logos |
|---|
| Barcode Symbologies | • • • • • • • • • • |
|---|
| Barcode Ratios | 2:1 (non-rotated) and 3:1 |
|---|
| 1D | B & C (User selectable/Auto), Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-14, EAN-8, German Post Code, GS1 Databar (formerly RSS), Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, MSI-3, Plessey, Plessey (MSI-1), Postnet, Postnet (5, 9, 11 & 13 digit) Japanese Postnet, RSS-14 (limited, truncated, stacked), Standard 2-of-5, UCC/EAN-128, UPC-A, UPC-A and UPC-E with EAN 2 or 5 digit extensions, UPC-E, UPC-E with 2 and 5 add on |
|---|
| 2D | Aztec, Codablock, Code 49, Data Matrix, MacroPDF-417, MaxiCode, MicroPDF417, PDF417, QR code |
|---|
| Options and Accessories | Dispenser—Label peel and present with label present sensor, KDU and KDU Plus™—Keyboard display units for stand-alone printing applications |
|---|
| BRAND | ZEBRA |
|---|
