| • • PHYSICAL CHARACTERISTICS | • • • • • • • • • • |
|---|
| Dimensions | MC3300 Gun/Pistol: 7.96 in. L x 2.94 in. W x 6.45 in. D 202.6 mm L x 74.7 mm W x 163.9 mm D, MC3300 Straight Shooter (45° Scan and 0° Scan): 7.96 in. L x 2.94 in. W x 1.35 in. D 202.2 mm L x 74.7 mm W x 34.5 mm D, MC3300 Turret/Rotating Head: 8.79 in. L x 2.94 in. W x 1.35 in. D 223.4 mm L x 74.7 mm W x 34.5 mm D |
|---|
| Weight | MC3300 (45° Scan): 13.5 oz./382 g, MC3300 Gun/Pistol: 17.8 oz./505 g, MC3300 Straight Shooter (0° Scan): 13.2 oz./375 g, MC3300 Turret/Rotating Head: 13.3 oz./377 g |
|---|
| Display | 4.0 inch capacitive; WVGA; color |
|---|
| Touchpanel | Corning® Gorilla® Glass touch panel with air gap |
|---|
| Backlight | LED backlight |
|---|
| Keypad | Numeric (29 Key), Function Numeric (38 Key), Alpha Numeric (47 Key) |
|---|
| Network Connections | Bluetooth, USB 2.0 High Speed (host and client), WLAN |
|---|
| EXPANSION SLOT | Micro SD card slot, up to 32GB |
|---|
| Notification | Audible tone plus multi-color LEDs, Vibrate |
|---|
| Imager Window | Corning Gorilla Glass |
|---|
| Voice and Audio | Audio Jack : All models except the Gun/Pistol: Integrated 2.5mm (Premium and Premium + models only — not available on Standard configurations), PTT Voice Support (Internal Speaker), speaker |
|---|
| • • Performance Characteristics | • • • • • • • • • • |
|---|
| CPU | Qualcomm 8056 1.8 GHz hexa-core 64 bit with power optimization |
|---|
| Operating System | Android 7.0 (Nougat) – AOSP, GMS – select configurations |
|---|
| Memory | 2GB/16GB Standard, 4GB/16GB Premium, 4GB/32GB Premium Plus |
|---|
| Power | MC3300 Gun/Pistol: Rechargeable Li-Ion: high capacity 5200 mAh; Fast charging support (new accessories), MC3300 Straight Shooter (45° Scan and 0° Scan)/ and Turret (Rotating Head): Rechargeable Li-Ion: standard 2700 mAh; High capacity 5200 mAh; Fast charging support (new accessories) |
|---|
| • • USER ENVIRONMENT | • • • • • • • • • • |
|---|
| Operating Temperature | -20° C to +50° C |
|---|
| Storage temperature | -20° C to +50° C |
|---|
| Humidity | 5% to 95% RH (Non-condensing) |
|---|
| Drop Specification | Multiple 5 ft./1.5 m drops to concrete over the entire operating temperature range |
|---|
| Tumble Specification | 1,000 3.2 ft./1 m tumbles |
|---|
| Sealing | IP54 |
|---|
| Thermal Shock | -40°C to 70°C |
|---|
| Electrostatic Discharge (ESD) | ± 15kv Air discharge, ± 8kv direct discharge, ± 8kv indirect discharge |
|---|
| Vibration | 5Hz to 2kHz |
|---|
| • •Interactive Sensor Technology (IST) | • • • • • • • • • • |
|---|
| Motion Sensor | 3-axis accelerometer, gyroscope |
|---|
| • • DATA CAPTURE | • • • • • • • • • • |
|---|
| Scanning | MC3300 (45° Scan): SE4750SR 2D, MC3300 Brick/Straight Shooter (0° Scan): SE965 1D, SE4750SR 2D, SE4850 ERI, MC3300 Gun/Pistol: SE965 1D, SE4750SR 2D, SE4850 ERI, MC3300 Turret/Rotating Head: SE965 1D Laser |
|---|
| CAMERA | 13MP with Flash (Premium + models only) (Not available on the MC3300 Gun/Pistol) |
|---|
| NFC | Available on Premium and Premium + models |
|---|
| • • WIRELESS LAN DATA COMMUNICATIONS | • • • • • • • • • • |
|---|
| Radio | 802.11 a/b/g/n/ac/d/h/i/k/r/w |
|---|
| Security | WEP, WPA/WPA2 Enterprise, WPA/WPA2 PSK |
|---|
| Data Rates | 2.4GHz: 144Mbps, 5GHz: 867Mbps |
|---|
| Certifications | 802.11n/ac, PMF, Voice Enterprise, Wi-Fi Direct, WMM-AC, WMM-PS, WPS |
|---|
| Fast Roam | 802.11r, Cisco CCKM, OKC, PMKID caching |
|---|
| • • WIRELESS PAN | • • • • • • • • • • |
|---|
| Bluetooth | V4.1, V2.1 + EDR w/ Bluetooth Low Energy (BLE) |
|---|
| BRAND | ZEBRA |
|---|
