| • • PHYSICAL CHARACTERISTICS | • • • • • • • • • • |
|---|
| Dimensions | 23.1 cm L x 9.1 cm W x 19.3 cm H, 9.1 in. L x 3.6 in. W x 7.6 in. H |
|---|
| Weight | 27 oz./765 g (includes battery) |
|---|
| Keyboard | 28-, 43- and 53-key, Terminal Emulation (5250, 3270, VT) |
|---|
| Display | 3.7 in. VGA resolution; color |
|---|
| Power | Lithium ion battery 2600 mAh, PowerPrecision Improved battery technology for better battery management |
|---|
| RFID | Integrated UHF Gen2 tag (Premium models only) |
|---|
| • • Performance Characteristics | • • • • • • • • • • |
|---|
| CPU | Dual core 800 MHz OMAP 4 processor |
|---|
| Operating System | Android 4.4.4 with Mobility Extensions (Mx), Microsoft Windows Embedded Compact 7.0, Microsoft Windows Embedded Handheld 6.5.3 |
|---|
| Memory | Premium models: 1GB RAM/2GB Flash, Standard models: 512MB RAM/2GB Flash |
|---|
| App Development | PSDK and EMDK available through Zebra Support Central Web site |
|---|
| Expansion | User accessible 32GB MicroSD card slot |
|---|
| Data Capture Options | SE1524-ER:2,4 1D extended range scan engine reads up to 45 ft./13.72 m away, SE4500-DL:2,5 1D/2D DL imaging engine reads 1D, 2D and PDF codes on driver’s licenses, SE4500-HD:2,5 1D/2D DPM imaging engine reads a wide variety of DPM marks on metal, plastic and glass, SE4750:2,4 Next generation omnidirectional 1D/2D imaging engine for faster data capture. Available in Standard Range (SR) and Mid Range (MR), SE4850,4: Extended range 1D/2D imager scans from 3 in. to 70 ft. (7.62 cm to 21.3 m), SE965:1,4 1D standard range scan engine |
|---|
| • • USER ENVIRONMENT | • • • • • • • • • • |
|---|
| Operating Temperature | -4° to 122° F/-20° TO 50° C |
|---|
| Storage temperature | -40° F to 158° F/-40° C to 70° C |
|---|
| Charging Temperature | 32° to 104° F/0° to 40° C |
|---|
| Humidity | 5% to 95% non condensing (Condensation resistant configurations available) |
|---|
| Drop Specification | meets/exceeds MIL-STD 810G, multiple 6 ft./1.8 m drops to concrete across the operating temp. range, Multiple 8 ft./2.4 m drops per MIL-STD 810G at room temperature |
|---|
| Tumble Specification | 2,000 3.28 ft./1 m tumbles (4,000 hits); meets and exceeds IEC tumble specifications |
|---|
| Sealing | IP64 (electronic enclosure, display and keypad) per IEC Sealing specification |
|---|
| Electrostatic Discharge (ESD) | ± 15kv Air discharge, ± 8kv direct discharge, ± 8kv indirect discharge |
|---|
| • • WIRELESS COMMUNICATIONS | • • • • • • • • • • |
|---|
| WLAN | Android: IEEE 802.11 a/b/g/n/d/h/i/k/r, WinCE/WEH: IEEE 802.11 a/b/g/n/d/h/i |
|---|
| Data Rates | 802.11a: up to 54 Mbps, 802.11b: up to 11 Mbps, 802.11g: up to 54 Mbps, 802.11n: up to 65 Mbps |
|---|
| Frequency Range | All country dependent: 802.11a – 5 GHz; 802.11b – 2.4 GHz; 802.11g – 2.4 GHz; 802.11n – 2.4GHz and 5GHz |
|---|
| Security | AES, CCXv4 certified, FIPS 140-2 certified, IPv6, LEAP, PEAP (MS-CHAP v2), PEAP-TLS, TLS-PAP, TTLS (MS-CHAP v2), TTLS (CHAP), TTLS-MD5, WEP (40 or 128 bit), TKIP, TLS, TTLS (MS-CHAP), WPA2, WPA2/AES |
|---|
| WPAN | Stonestreet stack: Bluetooth 4.0 plus BLE (Android only) or WBA Microsoft stack: Bluetooth Version 2.1 with EDR |
|---|
| Voice and Audio | High quality speaker, microphone (select configurations) and 2.5mm headset jack, Workforce Connect PTT Express (client included) with wired headsets |
|---|
| BRAND | ZEBRA |
|---|
