• • PHYSICAL CHARACTERISTICS | • • • • • • • • • • |
---|
Dimensions | 155 mm L x 75.5 mm W x 18.6 mm H, 6.1 in. L x 2.9 in. W x 0.73 in. H |
---|
Weight | 8.8 oz./249 g with battery |
---|
Display | 5.0 in. High Definition (1280 x 720), exceptionally bright, optically bonded to touch panel, outdoor viewable |
---|
Imager Window | Corning Gorilla Glass |
---|
Touch Panel | Corning® Gorilla® Glass, Dual mode capacitive touch with stylus or bare or gloved fingertip input (conductive stylus sold separately), fingerprint resistant anti-smudge coating, water droplet rejection |
---|
Backlight | LED backlight |
---|
Power | improved battery metrics for better battery management, Rechargeable Li-Ion, PowerPrecision+, > 15.48 Watt hours, > 4150 mAh |
---|
EXPANSION SLOT | User accessible MicroSD up to 32GB SDHC and up to 256 GB SDXC |
---|
Network Connections | High Speed (Host and Client), USB 2.0, WLAN, WPAN (Bluetooth) |
---|
Notification | Audible tone, multi-color LEDs, vibration |
---|
Keypad | On-screen keypad and enterprise keyboard |
---|
Voice and Audio | Bluetooth wireless headset support, cellular circuit switch voice, Front facing speaker, HD Voice, High quality speaker phone, PTT headset support, SWB & FB audio, Three microphone support with noise cancellation, vibrate alert |
---|
Button | dedicated push-to-talk button and volume up/down buttons, dual dedicated scan buttons, Six programmable buttons for maximum flexibility |
---|
• • Performance Characteristics | • • • • • • • • • • |
---|
CPU | Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz |
---|
Operating System | Android 10, upgradebale through A11/R3 |
---|
Memory | 4GB RAM/32GB Flash |
---|
• • USER ENVIRONMENT | • • • • • • • • • • |
---|
Operating Temperature | -4°F to 122°F/-20°C to 50°C |
---|
Storage temperature | -40°F to 158°F/-40°C to 70°C |
---|
Humidity | 5% to 95% non-condensing |
---|
Drop Specification | Multiple 4 ft/1.2m drops to tile over concrete -10°C to 50°C (14°F to 122°F), Multiple 6 ft. drops to concrete with the rugged boot accessory per Mil STD 810 G |
---|
Tumble Specification | 500 1.6 ft./0.5 m tumbles, meets or exceeds IEC tumble specification |
---|
Sealing | IP68 and IP65 per applicable IEC sealing specifications |
---|
Vibration | 0.04 g 2/Hz Random (20 Hz to 2 kHz), 4 g’s PK Sine (5 Hz to 2 kHz), 60 minute duration per axis, 3 axis |
---|
Thermal Shock | -40° F to 158° F/-40° C to 70° C rapid transition |
---|
Electro-Static Discharge | +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge |
---|
• •Interactive Sensor Technology (IST) | • • • • • • • • • • |
---|
Light Sensor | Automatically adjusts display backlight brightness |
---|
Magnetometer | eCompass automatically detects direction and orientation |
---|
Motion Sensor | 3-axis Accelerometer with MEMS Gyro |
---|
Proximity Sensor | Automatically detects when the user places the handset against head during a phone call to disable display output and touch input |
---|
• • DATA CAPTURE | • • • • • • • • • • |
---|
Scanning | Code 39 barcode: 20 Mil: 2.0 in. to 30.0 in./5.08 cm to 76.2 cm 4 Mil: 3.3 in. to 8.8 in./8.4 cm to 22.4 cm, Digimarc support, SE4710 imager (1D and 2D) with extraordinary range: Scan range |
---|
CAMERA | Front — 5 MP; f/2.0 aperture, Rear — 13 MP autofocus; f/2.2 aperture; flash LED generates balanced white light; supports Torch mode |
---|
NFC | FeliCa and ISO 15693 cards, ISO 14443 Type A and B, P2P mode and Card Emulation via Host |
---|
• • WIRELESS LAN | • • • • • • • • • • |
---|
Radio | 2×2 MU-MIMO, IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v3/w, IPv4, IPv6, Wi-Fi™ certified |
---|
Data Rates | 2.4GHz: 802.11b/g/n — up to 300 Mbps, 5GHz: 802.11a/n/ac — up to 866.7 Mbps |
---|
Operating Channels | Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency, Channel 1-13 (2412-2472 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, Channel 36-165 (5180-5825 MHz): 36,40,44,48,52 56,60,64,100,104,108,112,116,120,124,128,132,136,140,144,149,153,157,161,165, Channel Bandwidth: 20, 40, 80 MHz |
---|
Security and Encryption | EAP-PWD, EAP-TLS, LEAP, PEAPv0- MSCHAPv2, PEAPv1- EAP-GTC, WEP (40 or 104 bit), WPA/WPA2 Enterprise (TKIP and AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), WPA/WPA2 Personal (TKIP, and AES) |
---|
Certifications | WFA (802.11n, WMM-PS, 801.11ac, PMF) |
---|
Fast Roam | 802.11r, Cisco CCKM, OKC, PMKID caching |
---|
• • WIRELESS PAN | • • • • • • • • • • |
---|
Bluetooth | Bluetooth Low Energy (BLE), Bluetooth v5.0, Class 2 |
---|
BRAND | ZEBRA |
---|
