• • SPECIFICATION |
• • • • • • • • • •
|
Print Method |
Direct Thermal
|
Print Speed |
12.5% pattern, Up to 3 ips (76 mm/sec – Linerless), Up to 4 ips (102 mm/sec – Label)
|
PRINT RESOLUTION |
203 dpi
|
PRINT WIDTH |
Up to 104 mm
|
SENSOR |
Black Mark, Gap, Paper Cover Open, Paper End
|
Media Type |
Label, Linerless (Optional)
|
Media Width |
112 mm / 105 mm (Optional)
|
Media Roll Size |
Up to 56 mm
|
Media Thickness |
0.07 ~ 0.15 mm
|
Supply Method |
Easy Paper Loading
|
DIMENSION (W X D X H IN MM) |
143.0 x 138 x 66 mm
|
Weight |
Including battery: 530 g (1.17 Ibs.), Paper : 242 g (0.53 lbs.)
|
Electrical |
7.3 V Li-ion, 2600 mAh,, EnergyStar Certified, Rechargeable Charging time: Up to 4.0 hrs
|
Memory |
128 MB SDRAM, 256 MB Flash, 256 MB SDRAM, 512 MB Flash (Optional)
|
Interface |
• • • • • • • • • •
|
Standard Interface |
USB V2.0 HS + Serial
|
Optional Interface |
USB V2.0 HS + Serial + Bluetooth / WLAN
|
WLAN¹ |
802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) – WEP40/104, WPA1/2 (PSK, EAP)
|
Bluetooth² |
* Easy Bluetooth Pairing™ via NFC, V4.2 Classic / LE
|
Emulation |
BPL-C™ (CPCL), BPL-Z™ (ZPLII), SLCS™
|
Driver / Utility |
Bartender UL, Label Artist-II™, Linux / Mac CUPS Driver, OPOS / JPOS Driver, Utility Program, Virtual COM USB / Ethernet Driver, Windows Driver (Europlus / Seagull)
|
SDK / Plugin |
Android / iOS / Windows SDK, Chrome SDK, Cordova Plugin, Linux SDK, Xamarin SDK
|
Application |
Label Artist™ Mobile (Android, iOS), mPrint App (iOS)
|
• • ENVIRONMENTAL |
• • • • • • • • • •
|
Operating Temperature |
Operating: -15 ~ 50℃ (5 ~ 122℉), Storage: -30 ~ 70℃ (-22 ~ 158℉)
|
Operating Humidity |
Operating: 10 ~ 80% RH
|
Sealing |
IP54
|
Drop Rate |
1.8 m (6 ft.)
|
• •Fonts/Graphics/Symbologies |
• • • • • • • • • •
|
Fonts |
10 SLCS™, 16 BPL-Z™, 23 Code Page, 7 BPL-C™, One BPL-Z™, One SLCS™, Unicode supported (UTF-8, UTF-16LE,UTF-16BE)
|
Graphics |
Supporting user-defined fonts, graphics, formats, and logos
|
Barcode Symbologies |
• • • • • • • • • •
|
1D |
Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar (RSS-14), IMB, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, Standard 2-of-5, UPC-A, UPC-E, UPC/EAN extensions
|
2D |
Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39
|
Standard Accessories |
Battery Charger, Battery Pack, Belt Clip, Power Cord
|
Optional Accessories |
Belt Strap, Case, Cleaning Pen, Quad Battery Charger, Ram Mount Vehicle Holder, Serial / USB Cable, Shoulder Strap, Single Battery Cradle, Vehicle Charger, Vehicle Holder
|
Supplies |
B-linerlessTM : BIXOLON’s flexible and ecological linerless label consumables
|
