| • • SPECIFICATION | • • • • • • • • • • |
|---|
| Print Method | Direct Thermal |
|---|
| Print Speed | 12.5% pattern, Up to 60 mm/sec (Linerless), Up to 90 mm/sec (Receipt) |
|---|
| PRINT RESOLUTION | 203 dpi |
|---|
| PRINT WIDTH | Up to 104 mm |
|---|
| SENSOR | Black Mark (Optional positioning), Gap (Optional), Paper Cover Open, Paper End |
|---|
| Media Type | Linerless (Optional), Receipt and Label |
|---|
| Media Width | 112 mm / 105 mm (Optional) |
|---|
| Media Roll Size | Up to 57 mm |
|---|
| Media Thickness | 0.07 ± 0.005 mm |
|---|
| Supply Method | Easy Paper Loading |
|---|
| DIMENSION (W X D X H IN MM) | 143.0 x 138 x 66 mm |
|---|
| Weight | Including battery: 530 g (1.17 Ibs.), Paper : 242 g (0.53 lbs.) |
|---|
| Electrical | 7.3 V Li-ion, 2600 mAh,, EnergyStar Certified, Rechargeable Charging time: Up to 4.0 hrs |
|---|
| Memory | 8 MB SDRAM, 4 MB Flash |
|---|
| Interface | • • • • • • • • • • |
|---|
| Standard Interface | USB V2.0 FS + Serial |
|---|
| Optional Interface | USB V2.0 FS + Serial + Bluetooth¹ / WLAN² |
|---|
| Bluetooth¹ | Easy Bluetooth Pairing™ via NFC, V4.1 Classic & LE |
|---|
| WLAN² | 802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) – WEP40/104, WPA1/2(PSK, EAP) |
|---|
| • • ENVIRONMENTAL | • • • • • • • • • • |
|---|
| Operating Temperature | Operating: -15 ~ 50℃ (5 ~ 122℉), Storage: -30 ~ 70℃ (-22 ~ 158℉) |
|---|
| Operating Humidity | Operating: 10 ~ 80% RH |
|---|
| Sealing | IP54 |
|---|
| Drop Rate | 1.8 m (6 ft.) |
|---|
| • •Fonts/Graphics/Symbologies | • • • • • • • • • • |
|---|
| Character Size | CHN, Font A: 12 x 24, Font B: 9 x 17, Font C: 9 x 24, JPN: 24 x 24, KOR |
|---|
| Characters Per Line | CHN, Font A: 69, Font B, C: 92, JPN: 34, KOR |
|---|
| Character Sets | Alphanumeric: 95, Expanded Graphics: 128 x 33 page, International: 32, Optional Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
|---|
| Graphics | Supporting user-defined fonts, graphics, formats, and logos |
|---|
| Barcode Symbologies | • • • • • • • • • • |
|---|
| 1D | Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, ITF, UPC-A, UPC-E |
|---|
| 2D | Aztec, Data Matrix, GS1 Databar, MaxiCode, PDF417, QR code |
|---|
| Standard Accessories | Battery Charger, Battery Pack, Belt Clip, Paper, Power Cord |
|---|
| Optional Accessories | Belt Strap, Cigarette Lighter Charger, Quad Battery Charger, Serial / USB Cable, Shoulder Strap, Single Battery Cradle |
|---|
| Supplies | B-linerlessTM : BIXOLON’s flexible and ecological linerless label consumables |
|---|
