Posiflex-ZT-3715
Posiflex ZT 3715 Haydn ZT Series POS Terminal features innovative industry-first clamshell design that increases maintenance effectiveness by four times and redefines the traditional mechanical form factor
ر.ق7.00 for 3 item(s)
Posiflex-ZT-3715
The industry-first clamshell design
| Security and Clean Cable Management
|
IP-Rated Protection
| Secured USB Port
|
0-90° Foldable Angle
|
SKU: HS-3514W-1-2-2 Categories: All-In-One POS, Point Of Sale, Touchscreen POS Terminals Tags: all in one, Digital Display, Food & Beverage, Hospitality, Hotels POS Qatar, Jiva HS POS Qatar, one pos, Point of Sale, Point Of Sale Machines, POS Qatar, Posiflex POS Qatar, Product Pos Qatar, Restaurant POS Qatar Brand: Posiflex Products In Qatar
| • • SPECIFICATION | • • • • • • • • • • |
|---|---|
| Processor | Intel Bay Trail J1900 Quad Core CPU, up to 2.42 GHz, 2M Cache |
| System Memory | DDR3L SO-DIMM x 1, max. 8GB |
| Storage Device | SATA storage x 2 (one for HDD/SSD; the other for 1” SSD only) |
| Power Supply | 24V/60W |
| Built In Printer | 3” detachable printer w/auto cutter, 250 mm/sec (max.) |
| OS Support | Linux per request, POSReady 7, WE 8.1 Industry, Win 10 IoT, Win 7 |
| • • DISPLAY & TOUCH | • • • • • • • • • • |
| LCD | 14" TFT LCD |
| RESOLUTION | 1366 x 768 |
| TOUCH | True-flat PCAP touch with multi-touch support (IP65 on front panel) |
| • • I/O & EXPANSION | • • • • • • • • • • |
| SERIAL PORT | 3, DB9 x 2 + RJ50 x 1, 5V/12V support on all COM ports |
| STANDARD USB PORT | USB 2.0 x 4 |
| PARALLEL PORT | Yes |
| LAN PORT | 10/100/1000 Mb x 1 |
| DISPLAY PORT | VGA x 1, 12V support for Posiflex monitors |
| CR PORT | 1, control 2 CR via optional Y-cable (printer driven) |
| PS/2 PORT | Yes |
| Audio | Line-out x 1 |
| EXPANSION SLOT | Mini-PCIe slot x 1 |
| • • PHYSICAL DIMENSION | • • • • • • • • • • |
| DIMENSION (W X D X H IN MM) | 371.5 x 198 x 473 |
| Weight | 5.8 |
| • • ENVIRONMENTAL | • • • • • • • • • • |
| OPERATING CONDITION | 0°C – 40 °C, 20%RH – 90%RH (Equipped with HDD), 0°C – 50°C, 20%RH – 90%RH (Equipped with SSD) |
| STORAGE CONDITION | -20°C – 70°C, 10%RH – 90%RH |
| • • BUILT-IN OPTIONS | • • • • • • • • • • |
| MSR | 3 tracks ISO or JISII (HID/VCOM selection) |
| Finger Print Sensor | Optical type |
| WIFI | Mini-PCIe WiFi/BT module |
| RFID READER | Support MIFARE Ultralight and Classic 1K card (HID/VCOM Selectable) |
| Scanner | 2D barcode scanner |
| iBUTTON | Yes (cannot coexist with FPU) |
| 4G COMMUNICATION | Single SIM slot |
| BRAND | |
| ZT Series | ZT-3715E, ZT-3715 |
ZT-3715
| System Configuration | |
|---|---|
| Processor | Intel Tiger Lake UP3 Core i3-1115G4E, up to 3.90 GHz, 6M Cache Intel Tiger Lake UP3 Core i5-1145G7E, up to 4.10 GHz, 8M Cache Intel Tiger Lake UP3 Core i7-1185G7E, up to 4.40 GHz, 12M Cache |
| System Memory | DDR4 SO-DIMM x 2, max. 64GB |
| Storage Device | M.2 connector [SATA Signal Only] x 2 |
| RAID Function | Yes |
| Intel vPro Support | Yes, with Core i5 option |
| TPM Support | TPM 2.0 |
| Power Supply | 24V/60W |
| OS Support | Windows 10 IoT |
| Display & Touch | |
|---|---|
| LCD | 15″ TFT LCD |
| Resolution | 1024 x 768 |
| Touch | True-flat PCAP touch with multi-touch support (IP65 on front panel) |
| I/O Expansion | |
|---|---|
| Serial Port | 2, DB9 x 1 + RJ50 x 1 (5V/12V support on all COM ports) |
| Parallel Port | N/A |
| Standard USB Port | 5, USB 3.0 x 2 + USB 2.0 x 3 |
| PoweredUSB Port | N/A |
| OTG USB | N/A |
| LAN Port | 10/100/1000 Mb x 2 |
| Display Port | 1. Proprietary connector x1 for 2nd display 2. USB Type-C x 1 |
| CR Port | 1, control 2 CR via optional Y-cable, supporting 24V cash drawer |
| PS/2 Port | N/A |
| UPS Port | N/A |
| Audio | Internal 2W speaker x 1 |
| Expansion Slot | M.2 2230 x1 for Wi-Fi/BT |
| Physical Dimension | |
|---|---|
| Dimension (W x D x H in mm) | 353 x 206 x 319 |
| Weight (N. W. in kg) | 4.9 |
| Environmental | |
|---|---|
| Operating Condition | 0°C – 40°C, 20%RH – 90%RH |
| Storage Condition | -20°C – 70°C, 10%RH – 90%RH |
| Built-in Options | |
|---|---|
| WiFi | M.2 WiFi/BT module |
| Camera | 1MP wide angle camera |
| MSR | N/A |
| AG Glass | Cannot coexist with built-in camera |
| Attachment Options | |
|---|---|
| POS Monitor | PCAP touch TFT LCD: 10.1″ |
| Line Display | N/A |
| External UPS Pack For RT Series | N/A |
| Attachment | MSR; 2D Scanner; RFID; Fingerprint Sensor |
| Note | Specifications and design are subject to change before official product launch |
* The product information and specifications are subject to change without prior notice.
ZT-3715E
| System Configuration | |
|---|---|
| Processor | Intel Tiger Lake UP3 Core i3-1115G4E, up to 3.90 GHz, 6M Cache Intel Tiger Lake UP3 Core i5-1145G7E, up to 4.10 GHz, 8M Cache Intel Tiger Lake UP3 Core i7-1185G7E, up to 4.40 GHz, 12M Cache |
| System Memory | DDR4 SO-DIMM x 2, max. 64GB |
| Storage Device | M.2 connector [SATA Signal Only] x 2 |
| RAID Function | Yes |
| Intel vPro Support | Yes, with Core i5 option |
| TPM Support | TPM 2.0 |
| Power Supply | 24V/120W |
| OS Support | Windows 10 IoT |
| Display & Touch | |
|---|---|
| LCD | 15″ TFT LCD |
| Resolution | 1024 x 768 |
| Touch | True-flat PCAP touch with multi-touch support (IP65 on front panel) |
| I/O Expansion | |
|---|---|
| Serial Port | 2, DB9 x 1 + RJ50 x 1 (5V/12V support on all COM ports) |
| Parallel Port | N/A |
| Standard USB Port | 5, USB 3.0 x 2 + USB 2.0 x 3 |
| PoweredUSB Port | 24V PoweredUSB x 1 |
| OTG USB | N/A |
| LAN Port | 10/100/1000 Mb x 2 |
| Display Port | 1. Proprietary connector x1 for 2nd display 2. USB Type-C x 1 |
| CR Port | 1, control 2 CR via optional Y-cable, supporting 24V cash drawer |
| PS/2 Port | N/A |
| UPS Port | N/A |
| Audio | Internal 2W speaker x 1 |
| Expansion Slot | M.2 2230 x1 for Wi-Fi/BT |
| Physical Dimension | |
|---|---|
| Dimension (W x D x H in mm) | 353 x 206 x 319 |
| Weight (N. W. in kg) | 4.9 |
| Environmental | |
|---|---|
| Operating Condition | 0°C – 40°C, 20%RH – 90%RH |
| Storage Condition | -20°C – 70°C, 10%RH – 90%RH |
| Built-in Options | |
|---|---|
| WiFi | M.2 WiFi/BT module |
| Camera | 1MP wide angle camera |
| MSR | N/A |
| AG Glass | Cannot coexist with built-in camera |
| Attachment Options | |
|---|---|
| POS Monitor | PCAP touch TFT LCD: 10.1″ |
| Line Display | N/A |
| External UPS Pack For RT Series | N/A |
| Attachment | MSR; 2D Scanner; RFID; Fingerprint Sensor |
| Note | Specifications and design are subject to change before official product launch |
