POS Box TX-2000

Posiflex Products

The TX-2000/2100 Series is a no-frills fanless POS Box with all the essential functions and capabilities to satisfy businesses of all sizes, and represent one of the best value choices in the entry-level POS Box segment.

The TX-2000/2100 Series is a no-frills fanless POS Box with all the essential functions and capabilities to satisfy businesses of all sizes, and represent one of the best value choices in the entry-level POS Box segment.



Processor

Intel Bay Trail J1800 Dual Core CPU, up to 2.58 GHz, 1M Cache

System Memory

DDR3L SO-DIMM x 1, max. 4GB

Storage Device

SATA Storage x 1 + eMMC x 1, factory default HDD x 1

OS Support

Linux per request, POSReady 7, Windows 10 IoT, Windows 7, Windows Embedded 8.1 Industry

SERIAL PORT

4, DB9 x 2 + RJ50 x 2, 5V/12V support on all COM ports

PARALLEL PORT

1

STANDARD USB PORT

USB 2.0 x 6

LAN PORT

10/100/1000 Mb x 1

DISPLAY PORT

VGA x 2 (12V support for Posiflex monitors)

CR PORT

1, control 2 CR via optional Y-cable

PS/2 PORT

Yes

Audio

Line-out

EXPANSION SLOT

Mini-PCIe slot x 1

• • BUILT-IN OPTIONS

• • • • • • • • • •

Built-in WiFi

Optional mini-PCIe WiFi/BT module

• • PHYSICAL DIMENSION

• • • • • • • • • •

DIMENSION (W X D X H IN MM)

220 x 202 x 56

WEIGHT (N. W. IN KG)

1.12

• • ENVIRONMENTAL

• • • • • • • • • •

OPERATING CONDITION

0°C – 40°C, 20%RH – 90%RH (Equipped with HDD), 0°C – 50°C, 20%RH – 90%RH (Equipped with SSD)

STORAGE CONDITION

-20°C – 70°C, 10%RH – 90%RH
