ZXP Series 7 Card Printer
PAIRING OUTSTANDING PRINT QUALITY WITH FAST PRINT SPEEDS
Extending Zebra’s line of card printers, the ZXP Series 9™ is a retransfer card printer specifically engineered for high-security applications. With industry-leading throughput enabling you to print more cards faster and with outstanding quality. Take control with the printer’s user-selectable print quality mode, allowing you to optimize for print speed or sharpen print quality. And, the dual-sided, simultaneous retransfer process provides best-in-class printing, encoding and laminating throughput.
GENUINE ZEBRA SUPPLIES
The choice of card-printer supplies is critical: supplies are the number one factor impacting the reliability and consistency of card printing, as well as print quality. Genuine Zebra™ supplies meet stringent quality standards. Our supplies deliver consistent results with every print job and minimize wear and tear on critical printer parts—resulting in reduced overall maintenance costs.
Zebra’s PVC and Composite PVC cards are guaranteed ISO-compliant. Zebra offers cards with tamper-resistant embedded holograms, magnetic stripes and smart chips—which can be encoded on-demand with a Zebra card printer—for maximum security and functionality. Select from Zebra’s portfolio of stock cards, or design a unique custom card to best reflect your brand or meet your organization’s security needs.
QUALITY, DEPENDABILITY, FLEXIBILITY AND SPEED
Government, Education, Retail and Hospitality industries have an ever-increasing focus on security, a need for flexibility and a continual demand for efficiency.
Outstanding Print Quality + Fast Print Speeds
Produce durable, long-lasting, tamper-resistant cards with the sharpest photo-like image quality that boasts rich, consistent colors and strikingly sharp resolution. Industry-leading throughput allows you to print more cards faster—even with dual-sided lamination and encoding.
| • • SPECIFICATION | • • • • • • • • • • |
|---|---|
| STANDARD FEATURES | 100 card covered feeder (30 mil), 16-character LCD operator control display, 300 dpi (11.8 dots/mm) print resolution, 45 card capacity output hopper (30 mil), Auto calibration of ribbon, Eco-Friendly Load-N-Go drop-in ribbon cartridges, Microsoft® Certified Windows drivers, Print Touch NFC tag for online printer documentation and tools, Two-year (unlimited passes) original printhead, Two-year warranty on printer, USB 2.0 connectivity, ZRaster™ host-based image processing |
| Printing | 130 cph YMCKO, 545 cph monochrome, Dye-sublimation thermal transfer direct to card, Edge-to-edge printing on standard CR-80 media, Full color or monochrome printing, Single-sided printing |
| Ribbon | Black Monochrome: 1000 images/roll, White Monochrome: 500 images/roll, YMCKO: 100 images/roll |
| Card Thickness | 10 – 40 mil |
| Card Size | 2.12" (54 mm) x 3.38" (86 mm), CR-80, ISO 7810 format, Type ID-1 |
| Card Material | PVC and PVC composite |
| • • ENVIRONMENTAL | • • • • • • • • • • |
| OPERATING CONDITION | Operating Humidity: 20% to 65% non-condensing, Operating Temperature: 60ºF to 86ºF/15ºC to 30ºC, Storage Humidity: 20% to 70% non-condensing, Storage Temperature: 23ºF to 131ºF/-5ºC to 55ºC |
| Media Storage | Do not store in direct sunlight, Humidity: 35% to 65% non-condensing, Temperature: 41ºF to 77ºF/5ºC to 30ºC |
| Electrical | Auto-switching single-phase AC power, FCC Class A, Frequency range: 47-63 Hz, Operating range: 90-132VAC and 190-264VAC RMS |
| Interface | Built-in 10/100 Ethernet — optional*, USB V2.0 (cable included) — standard |
| Length | 9.3" (236 mm) |
| Width | 7.9" (200 mm) |
| Height | 13.0" (330 mm) |
| Weight | 11.6 lbs (5.3 kg) |
| Microsoft Windows® Certified Printer Drivers Supported | Windows 7® (32 and 64 bit), Windows 8® and Win 8 Pro (32 and 64 bit), Windows Server 2008 (32 and 64 bit), Windows Server 2012 (64 bit), Windows Server® 2003 (32 bit), Windows Vista® (32 and 64 bit), Windows® XP (32 bit) |
| Optional Features | 10/100 Ethernet connectivity, 30 mil cards only, high and low coercivity, Magnetic stripe encoder — ISO 7811 (new and pre-encoded); tracks 1, 2 and 3, Manual front card feeder bezel*, Single card cleaner rolling kit*, stripe down, Zebra OneCare extended product warranty programs |
| Product Warranty | For the complete warranty statement, please visit: www.zebra.com/warranty., The ZXP Series 1 is warranted against defects in workmanship and materials for a period of 2 (two) years from the date of shipment. |
| BRAND |
Printer Names
|
ZXP Series 7
ZXP Series 7 Pro |
Standard Features
| • 300 dpi/11.8 dots per mm print resolution • USB 2.0 and Ethernet 10/100 connectivity • Microsoft® Windows Certified drivers • 15-card reject hopper (30 mil) • ZXP Series 7 and Series 7 Pro: 250-card input capacity feeder (30 mil) • ZXP Series 7: 100-card output hopper (30 mil) • ZXP Series 7 Pro: 250 First-in, First-out mechanical output hopper • Single-card feed capability • ix Series intelligent media technology • 21-character x 6-line LCD operator display with configurable soft keys • Kensington® physical lock slot • Two-year limited warranty on printer and printhead |
Printing and Laminating Specifications
| • Color dye sublimation or monochrome thermal-transfer printing • Single- and dual-sided printing • Near photographic print quality • Edge-to-edge printing on standard CR-80 media • Simultaneous printing, encoding, and laminating capability • One-pass single- and dual-sided wasteless lamination • 1375 cards / hour monochrome single-sided or 555 cards / hour dual sided printing • 300 cards / hour full-color YMCKO single-sided printing • 225 cards / hour full-color YMCKOK dual-sided printing • 270 cards / hour full-color YMCKO single-sided printing with lamination NOTE: Printing throughput (cards per hour) based on batch printing with USB connectivity. Times may vary depending on the computer configuration. |
Media Specifications
| Zebra’s intelligent technology RFID tags authenticate and automate ix Series ribbons and i Series laminates Card cleaning rollers included with each ribbon carton Specially designed cleaning supplies simplify preventative maintenance True Colours ix Series Ribbons • YMCKO: 250 or 750 images / roll True Secure i Series Laminates • Linerless waste-free 1.0 mil top and bottom laminate: 750 images / roll Card Compatibility For optimum card quality and printer performance, use genuine Zebra card supplies. For more information, visit • Card thickness: 10 – 50 mil (0.25 – 1.27 mm) |
Operating Characteristics
| Environmental | Operating Temperature: 59ºF to 95ºF/15ºC to 35ºC Operating Humidity: 20% to 80% non-condensing Storage Temperature: 23ºF to 158ºF/-5ºC to 70º C Storage Humidity: 10% to 90% non-condensing Media Storage:
|
| Electrical | Auto-switching single-phase AC power 90V – 264V AC and 47 – 63Hz (50 – 60Hz nominal) FCC Class A |
Physical Characteristics
| Dimensions | ZXP Series 7: Printer only: 12 in. H x 10.9 in. L x 27.5 in. W 306 mm H x 277 mm D x 699 mm W Printer with laminator: 12 in. H x 10.9 in. L x 38 in. W 306 mm H x 277 mm D x 964 mm W ZXP Series 7 Pro: Printer only: 13.75 in. H x 10.9 in. L x 28.25 in. W 349 mm H x 277 mm D x 718 mm W |
| Weight | ZXP Series 7: Printer only: 26.9 lbs/12.2 kg Printer with laminator: 39.5 lbs/17.9 kg ZXP Series 7 Pro: Printer only: 31.7 lbs/14.4 kg Printer with laminator: 44.3 lbs/20.1 kg |
Communication and Interface Capabilities
|
Software Tools
| ZMotif SDK support and sample code available Windows 7® (32 and 64 bit), Windows Server 2008 (32 and 64 bit) Windows 8® (32 and 64 bit), Windows 8.1® (32 and 64 bit), Windows Server 2012 (64 bit), Windows 10 (32 and 64 bit) CardStudio card design and issuance software NOTE: Please see |
Optional Features
| • Single and dual-sided laminator • Optional contact/contactless SmartCard encoding option module • FIPS 201 compliant dual-sided laminator (only for North America) • Lockable enclosures and card feeder • Extended product warranty programs • 802.11b/g wireless connectivity • 1D barcode scanner • Duo-Print upgrade kit Encoding Options and Specifications • Magnetic stripe encoder — AAMVA and ISO 7811 (new and pre-encoded, tracks 1, 2, and 3, high and low coercivity) |
Zebra Synchronized Supplies for Operational Efficiency and Lower Costs
| Color Print Operations | Ribbon Media 750 Images per ribbon** 250 Card Capacity Input and Output Hopper 3X synchronized card input and ouput: 250 cards (x3) = 750 = 3 full card feeder cassettes per YMCKO ribbon |
| Mono Print Operations | Ribbon Media 5,000 Images per ribbon 250 Card Capacity Input and Output Hopper 20X synchronized card input and ouput: 250 cards (x20) = 5,000 = 20 full card feeder cassettes per black mono ribbon |
