BEACH BUTLER

04. LRS

Lying on the beach or sunbathing by the pool, your guests should never have to get up to find a waiter so they can order their food and drinks. With the Beach Butler Waiter Calling System, they no longer have to. They simply push a button and the waiter is instantly paged.

Lying on the beach or sunbathing by the pool, your guests should never have to get up to find a waiter so they can order their food and drinks. With the Beach Butler Waiter Calling System, they no longer have to. They simply push a button and the waiter is instantly paged.



• • SPECIFICATION

• • • • • • • • • •

Operating Environment

Humidity: <95% (non-condensing), Operating temperature range: 0 to 45 degrees Celsius, Transport temperature range: -20 to 60 degrees Celsius

Power

Battery pack: Alkaline 2 x AA

Paging Transmitter

Antenna: Internal antenna, Bandwidth: 445.0 kHz, Deviation: 3.75 kHz, Frequency Range: 433-470 MHz, Modulation: FSK (Frequency Shift Keying), OTA Baud rate: 1200, Power Output: <10mW

M ax Power ERRP

Power Output:<10mW

Supported Paging Protocols

POCSAG

User Interface

1 or 2 Push Buttons, Buzzer, Connector for Use with LRS Programmer

Regulatory Certifications

ANSI C63.4:2009, European Community: EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2010, FCC Part 15 Subpart C:2008, United States and Territories: FCC Part 15.231

Dimensions

2.75 (wide) inches x 6.88 (height)inch

Ordering Information

TX-17XX – 434 (Algeria, Bahrain, Egypt, Jordan, Kuwait, Morocco, Oman, Qatar and Tunisia), TX-17XX – 467 (Cyprus, Iraq, Iran, Lebanon, Libya, Saudi Arabia, Turkey, U.A.E and Yemen)

Frequency Shipped

434.000MHz (Algeria, Bahrain, Egypt, Jordan, Kuwait, Morocco, Oman, Qatar and Tunisia), 467.750MHz (Cyprus, Iraq, Iran, Lebanon, Libya, Saudi Arabia, Turkey, U.A.E and Yemen)
