| • • SPECIFICATION | • • • • • • • • • • |
| Print Method | Direct Thermal, Thermal Transfer |
| Print Speed | SLP-TX220: Up to 6 ips (152 mm/sec), SLP-TX223: Up to 4 ips (100 mm/sec) |
| PRINT RESOLUTION | SLP-TX220: 203 dpi, SLP-TX223: 300 dpi |
| PRINT WIDTH | SLP-TX220: Up to 54 mm, SLP-TX223: Up to 56.9 mm |
| PRINT LENGTH | Up to 2,000 mm |
| SENSOR | Head open, Reflective (adjustable), Transmissive |
| Media Type | Black Mark, Continuous, Fan-Fold, Gap, Notch |
| Media Width | 15 ~ 60 mm |
| Media Roll Size | Up to 130 mm |
| Media Thickness | 0.06 ~ 0.20 mm |
| Supply Method | Easy Paper Loading |
| Inner Core | 12.5 ~ 38.1mm |
| Ribbon Type | Outside, Resin, Wax, Wax/Resin |
| Ribbon Width | 12.5 mm, 58 mm |
| Ribbon Length | Up to 74 m |
| DIMENSION (W X D X H IN MM) | 144 x 252 x 173 mm |
| Weight | 1.71 kg (3.77 lbs.) |
| Electrical | 50/60Hz, EnergyStar Certified, External Power Adaptor 100-240V AC |
| Memory | 64 MB SDRAM, 128 MB Flash |
| Interface | • • • • • • • • • • |
| Standard Interface | USB + Serial + Parallel |
| Optional Interface | USB + Serial + Ethernet + WLAN, USB + WLAN* + Bluetooth |
| WLAN¹ | 802.11a/b/g/n/ac USB dongle type |
| Bluetooth² | Built-in type, MFi iAP2 certified |
| Real Time Clock | Supported |
| • • ENVIRONMENTAL | • • • • • • • • • • |
| Operating Temperature | Operating: 5 ~ 40℃ (41 ~ 104℉), Storage: -20 ~ 60℃ (-4 ~ 140℉) |
| Operating Humidity | Operating: 10 ~ 80% RH, Storage: 10 ~ 90% RH |
| Emulation | BPL-E™ (EPL), BPL-Z™ (ZPLII), SLCS™ |
| Driver / Utility | Bartender Ultralite for BIXOLON, Label Artist-II™, Linux / Mac CUPS Driver, OPOS / JPOS Driver, Utility Program, Virtual COM USB / Ethernet Driver, Windows Driver (Europlus / Seagull) |
| SDK / Plugin | Android / iOS / Windows SDK, Chrome SDK, Linux SDK, Xamarin SDK |
| Application | Label Artist™ Mobile (Android, iOS), mPrint App (iOS), mPrint Server (Windows, iOS) |
| MDM | BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android) |
| • •Fonts/Graphics/Symbologies | • • • • • • • • • • |
| Fonts | 10 SLCS™, 16 BPL-Z™, 23 Code Page, 5 BPL-E™, One BPL-Z™, One SLCS™, Unicode supported (UTF-8, UTF-16LE,UTF-16BE) |
| Graphics | Supporting user-defined fonts, graphics, formats, and logos |
| Barcode Symbologies | • • • • • • • • • • |
| 1D | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar (RSS-14), Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, Standard 2-of-5, UPC-A, UPC-E, UPC/EAN extensions |
| 2D | Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
| Optional Accessories | Auto Cutter, External Paper Supply, Peeler, WLAN Dongle (Consensus required) |
