| • • DURABILITY | • • • • • • • • • • |
|---|
| Drop Test | 5’ drop tested onto plywood over concrete, Operating temperature range: -20°C to 60°C |
|---|
| Ingress | IP68 |
|---|
| Internal | Magnesium-alloy internal frame |
|---|
| External | Rubberized enclosure |
|---|
| • • SYSTEM FEATURES | • • • • • • • • • • |
|---|
| Operating System | Android 8.0 (Oreo™) |
|---|
| Processor | 64bit up to 2.0Ghz, Qualcomm 8953 Octa-Core, Snap Dragon 625 Family |
|---|
| Memory | 4GB LPDDR3 |
|---|
| Storage Options | Card Slot: MicroSD up to 128GB, Internal: 32 GB eMMC |
|---|
| Display | 5 Point Capacitive Touch, 550 Nits with Ambient Light Sensor, 6.0” FHD 1920×1080 View Anywhere® Display, Wet and Glove Touch Capability |
|---|
| SIM Card | Dual Nano SIM (4GFF) |
|---|
| CAMERA | Front: 5 MP, Main/Rear: 13 MP |
|---|
| Supported Frequencies | CA: – UL Intra-C: Band39/Band40/Band41 – UL Intra-C: Band3/Band39/Band40/Band41 – DL Inter: Band1+Band3 Band39+Band41, CDMA/EVDO: BC0, GSM: B2/B3/B5/B8(850/900/1800/1900), LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B17/B20/B28, LTE-TDD:B38/B39/B40/B41, TD-SCDMA: B34/B39, WCDMA:B1/B2/B5/B8 |
|---|
| Ports | Accessory, USB Type C |
|---|
| Connectivity | Bluetooth 4.1, GNSS GPS, GLONASS, Beidou, Galileo, NFC 13.56 Mhz, WLAN 802.11ac |
|---|
| Battery Life & Power | 30.4 Whr, Field Replaceable, Full charge time up to 5hrs, 80% charge in 2hrs, Input Voltage: 5V 2.5A rapid charger, Up to 22hrs runtime |
|---|
| Sensors | Ambient Light Sensor, Barometer, Compass, Gravity, Proximity |
|---|
| Security | Device Lock Authentication, Qualcomm Processor Security, Whole Device Encryption |
|---|
| Audio | Handsfree Speaker, Integrated voice speaker and microphone, Noise Reduction Mic |
|---|
| Dimensions / Weight | 0.81lb (369g), 6.5” x 3.7” x 0.55” (165 mm x 94.2 mm x 14 mm) |
|---|
| Keypad | Front: F1, F2, FN, Power, Side: PTT/BCR Key, Volume +/-, Touch: Home, Menu, Return |
|---|
| Enterprise Management | Compatible with Airwatch, Mobile Iron, and SOTI MDM software packages, Firmware Over The Air updating (FOTA) supported by Redbend™ |
|---|
| Environmental | Operating Temperature: -20 °C to 60 °C / -4 °F to 140 °F, Storage Temperature: -40 °C to 70 °C / -40 °F to 158 °F |
|---|
| • • REGULATORY & ENVIRONMENT | • • • • • • • • • • |
|---|
| Immunity | CISPR 24, EN55024 (US, CAN, EU) |
|---|
| Safety | CB Scheme, IEC 60950 (US, CAN, EU), NRTL |
|---|
| Emissions | CFR47 Part 15, Subpart B, CISPR 32, EN55032, ICES-003 for Class B |
|---|
| Environment | CEC, RE Directive, RoHS 2 Directive, WEEE Directive |
|---|
| BRAND | ZEBRA |
|---|
