| • • PHYSICAL CHARACTERISTICS | • • • • • • • • • • |
|---|
| Dimensions | 240 mm L x 88 mm W x 189 mm H, 9.4 in. L x 3.5 in. W x 7.4 in. H |
|---|
| Weight | 26.9 oz./765g with battery |
|---|
| Display | 4.3 in. WVGA (800 x 480), color display |
|---|
| Imager Window | Corning Gorilla Glass |
|---|
| Touchpanel | Corning Gorilla Glass with air gap (standard model) or optically bonded (freezer model), Dual mode capacitive touch with bare or gloved fingertip input, screen protector (sold separately) |
|---|
| Backlight | LED backlight |
|---|
| Power | (Freezer Capacity battery — 5000mAh), Both batteries offer: PowerPrecision+ with improved battery technology for longer cycle times and real-time visibility into battery metrics for better battery management, fast charging (up to 2.4A), hot swap battery backup with temporary session persistence, Rechargeable Li-Ion: 3.6V, 7000mAh |
|---|
| EXPANSION SLOT | User accessible MicroSD with 32GB SDHC and up to 256GB SDXC |
|---|
| Network Connections | USB 2.0 High Speed (Host & Client), WLAN, WPAN (Bluetooth) |
|---|
| Notification | Audible tone, haptic feedback, multi-color LEDs |
|---|
| Keypad | 29 Key Numeric/Calculation, 34 Key Numeric/Function, 43 Key, 53 Key Alpha-Numeric STD, 53 Key Terminal Emulation (5250 and VT), 58 Key Alpha- Numeric, Backlit, Field replaceable keypads |
|---|
| Voice and Audio | Microphone, PTT Voice (Internal Speaker and Bluetooth Wireless Headset Support), speaker |
|---|
| • • Performance Characteristics | • • • • • • • • • • |
|---|
| CPU | Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz |
|---|
| Operating System | Android 8.1 Oreo with Zebra’s Restricted Mode for control over GMS and other services, upgradeable through Android R |
|---|
| Memory | 4 GB RAM/32 GB Flash pSLC |
|---|
| • • USER ENVIRONMENT | • • • • • • • • • • |
|---|
| Operating Temperature | Freezer: -22°F to 122°F/-30°C to +50°C, Standard: -4°F to 122°F/-20°C to +50°C |
|---|
| Storage temperature | -40° F to 158° F/-40° C to 70° C |
|---|
| Humidity | Freezer: 5% to 95%, condensing (Condensation resistant model with integrated exit window heater), Standard: 5% to 95%, non-condensing |
|---|
| Drop Specification | Freezer: 7 ft. (2.1m) drops to concrete across temperature per MIL-STD-810G, Standard: 8 ft. (2.4m) drops to concrete across temperature per MIL-STD-810G |
|---|
| Tumble Specification | 4,000 3.3 ft. (1m) tumbles; meets and exceeds IEC tumble specification |
|---|
| Sealing | IP67 and IP65 per applicable IEC sealing specifications |
|---|
| Vibration | 0.04 g 2/Hz Random (20 Hz to 2 kHz), 4 g’s PK Sine (5 Hz to 2 kHz), 60 minute duration per axis, 3 axis |
|---|
| Thermal Shock | -40°F to 158°F (-40° C to 70°C) rapid transition |
|---|
| Electrostatic Discharge (ESD) | ± 15kv Air discharge, ± 8kv direct discharge, ± 8kv indirect discharge |
|---|
| • • DATA CAPTURE | • • • • • • • • • • |
|---|
| Scanning | SE4750 DPM: Direct Part Mark (DPM) imager, SE4750: 1D/2D standard range omnidirectional imager, SE4770: 1D/2D standard range omnidirectional imager, SE4850: 1D/2D extended range imager, SE965: 1D standard range laser scanner |
|---|
| CAMERA | Front: 5MP fixed focus, 2.0 aperture, Rear: 13MP autofocus, 2.2 aperture, flash LED generates balanced white light, support torch mode, supports rear camera barcode scanning |
|---|
| NFC | FeliCa and ISO 15693 cards, ISO 14443 Type A and B, P2P mode and Card Emulation via Host (HCE) support, Tap to Pair |
|---|
| • • WIRELESS LAN | • • • • • • • • • • |
|---|
| Radio | 2×2 MU-MIMO, IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/w, IPv4, IPv6, Wi-Fi™ certified |
|---|
| Security | AES, CCXv4 certified, FIPS 140-2 certified, FIPS 140-2 Level 1: Data in Motion and Data at Rest, LEAP, PEAP (MS-CHAP v2), PEAP-TLS, TLS-PAP, TTLS (MS-CHAP v2), TTLS (CHAP), TTLS-MD5, WEP (40 or 128 bit), TKIP, TLS, TTLS (MS-CHAP), WPA2 |
|---|
| Data Rates | 2.4GHz: 802.11b/g/n — up to 300 Mbps, 5GHz: 802.11a/n/ac — up to 866.7 Mbps |
|---|
| Operating Channels | Actual operating channels/frequencies depend on regulatory rules and certification agency, Chan 1-13 (2412-2472 MHz), Chan 8-165 (5040 – 5825 MHz), Channel Bandwidth: 20, 40, 80 MHz |
|---|
| Multimedia | Wi-Fi Multimedia (WMM and WMM-PS; Including TSPEC) |
|---|
| Certifications | WFA (802.11n, WMM-PS, 802.11ac, PMF, WMM-AC, Voice Enterprise, WiFi Direct and WPS 2.0) |
|---|
| Fast Roam | 802.11r, Cisco CCKM, OKC, PMKID caching |
|---|
| • • WIRELESS PAN | • • • • • • • • • • |
|---|
| Bluetooth | Bluetooth V5.0 with BR/EDR and Bluetooth Low Energy (BLE) Support, Class 2 |
|---|
| • •Interactive Sensor Technology (IST) | • • • • • • • • • • |
|---|
| Ambient Light Sensor | Automatically adjusts display & keypad backlight brightness |
|---|
| Motion Sensor | 3-axis Accelerometer with MEMS Gyro |
|---|
| BRAND | ZEBRA |
|---|
