| • • PHYSICAL CHARACTERISTICS | • • • • • • • • • • |
|---|
| Dimensions | 225 mm L x 98 mm W x 44 mm D (at display); 31 mm D (at grip area), 8.86 in. L x 3.86 in. W x 1.73 in. D (at display); 1.22 in. D (at grip area) |
|---|
| Weight | 1.34 lbs./610 g (basic unit with battery) |
|---|
| Display | 2 Touchscreen options: High Visibility option, Extreme Duty option, 3.7” VGA (640 x 480) Transflective Color/Touch Display |
|---|
| Battery | PowerPrecision Lithium ion battery 5000 mAh |
|---|
| Keypad Options | 36-key Numeric, 36-key Numeric Alpha Modified, 55-key Alpha Numeric, 59-key full alpha numeric, 66-key QWERTY Numeric 36-key Numeric, Ultra-white backlight |
|---|
| Voice and Audio | high volume 95dBA beeper, Integrated microphone and speaker, optional push-to-talk speaker, vibration feedback |
|---|
| CAMERA | 3 Mega pixel, 4X digital zoom, autofocus, Dual LED flash, Video capable |
|---|
| GPS | SIRF III GPS Receiver |
|---|
| • • Performance Characteristics | • • • • • • • • • • |
|---|
| CPU | TI OMAP 3, 800 MHz |
|---|
| Operating System | Microsoft® Windows® Embedded Handheld 6.5, Windows® CE 6.0 |
|---|
| Memory | 512 MB RAM and 1GB Flash |
|---|
| Bundled Applications | Internet Explorer Mobile; Windows Office Outlook Mobile; Windows Media Player Mobile, Windows CE 6.0: Internet Explorer Embedded; Microsoft Wordpad, Windows Embedded Handheld 6.5: Windows® Office Mobile 2010 (includes Word, Excel, PowerPoint, OneNote and SharePoint |
|---|
| Terminal Emulation | TekTerm, Wavelink TE |
|---|
| Additional Software | Kiosk, Mobile Control Center (MCC), NetMotion Mobility XE VPN, Total Recall/TweakIt/Dr. Debug |
|---|
| • • USER ENVIRONMENT | • • • • • • • • • • |
|---|
| Operating Temperature | -20°C to +50°C / -4°F to +122°F |
|---|
| Storage temperature | -40°C to +60°C / -40°F to +140°F |
|---|
| Humidity | 5% to 95% non-condensing |
|---|
| Drop Specification | Multiple 6.5 ft./2 m drops to polished concrete |
|---|
| Sealing | IEC 60529, IP65, IP67 |
|---|
| Electrostatic Discharge (ESD) | +/- 15kv air discharge, +/- 8kV contact |
|---|
| • • WIRELESS COMMUNICATIONS | • • • • • • • • • • |
|---|
| WLAN | 64/128 WEP, AESCCMP, CCX v4, 802.1X, WPA / WPA2-Enterprise & Shared Key, FAST-MSCHAPv2, IEEE 802.11a/b/g/n, LEAP, PEAPv0-MSCHAPv2, PEAPv1-GTC, TKIP, TLS |
|---|
| Narrowband* (optional) | Channel Spacing: 12.5 – 25 kHz, RF power: 500 – 1,000mW; Transmission speed: 4.8/9.6 kbps @ 12.5 kHz, 9.6/19.2 kpbs @ 25 kHz, UHF bands: 403 – 470 MHz |
|---|
| WWAN (optional) | 2.5G GSM/GPRS/EDGE radio, Five Band UMTS: 800/850, 900, 1900, 2100 MHz, Quad-Band GSM: 850, 900, 1800, 1900 MHz, Quad-Band GSM: 850, 900, 1800, 1900 MHz, UMTS 3.8G HSPA+ radio |
|---|
| WPAN | Bluetooth® V2.0 + EDR |
|---|
| BARCODE SCANNER OPTIONS | SE1224HP 1-D Laser, SE1524ER Extended Range Laser, SE4500 1-D/2-D Standard Range Imager, SE4600 1-D/2-D Extended Range Imager, SE955 1-D Laser, SE965 1-D Laser |
|---|
| HF Module | Class A, B and C, Data encryption: 2 SAM slots, Frequency: 13.56 MHz, full Mifare support, ID1 SAM format, ISO 15693; NFC “Reader to Tag” Mode, Protocols supported: ISO14443 type A, B and C |
|---|
| Accessories | 2-D and AutoRange Scanners, 6-Slot Spare Battery Charger, Carry Accessories, Desktop Docking Station, Integrated 1-D, Switchable Keyboard, Vehicle Cradle |
|---|
| BRAND | ZEBRA |
|---|
