| • • SPECIFICATION | • • • • • • • • • • |
|---|
| Print Method | Direct Thermal |
|---|
| Print Speed | 12.5% pattern, Up to 5 ips (127 mm/sec – Label, Linerless) |
|---|
| PRINT RESOLUTION | 203 dpi |
|---|
| PRINT WIDTH | Up to 72 mm |
|---|
| SENSOR | Black Mark, Gap, Label Presence, Paper Cover Open, Paper End |
|---|
| Media Type | Label, Linerless (Optional) |
|---|
| Media Width | 25 ~ 80 mm |
|---|
| Media Roll Size | Up to 66 mm |
|---|
| Media Thickness | 0.07 ~ 0.15 mm |
|---|
| Inner Core | 19mm, 12mm |
|---|
| Supply Method | Easy Paper Loading |
|---|
| DIMENSION (W X D X H IN MM) | 119.0 x 159.0 x 79.0 mm |
|---|
| Weight | Including battery: 694 g (1.53 Ibs.), Paper: 257 g (0.57 lbs.) |
|---|
| Electrical | 7.3 V Li-ion, 2600 mAh,, EnergyStar Certified, Rechargeable Charging time: Up to 4.0 hrs |
|---|
| Peeler | Supported |
|---|
| Paper Guide | Yes (Inner core: 19mm) |
|---|
| Display | FSTN LCD (200 x 100 pixels) |
|---|
| Memory | 128 MB SDRAM, 256 MB Flash, 256 MB SDRAM, 512 MB Flash (Optional) |
|---|
| Interface | • • • • • • • • • • |
|---|
| Standard Interface | USB V2.0 HS + Serial |
|---|
| Optional Interface | USB V2.0 HS + Serial + Bluetooth / WLAN / Dual Bluetooth + WLAN |
|---|
| Bluetooth² | * Easy Bluetooth Pairing™ via NFC, V4.2 Classic / LE |
|---|
| WLAN¹ | 802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) – WEP40/104, WPA1/2 (PSK, EAP) |
|---|
| • • ENVIRONMENTAL | • • • • • • • • • • |
|---|
| Operating Temperature | Operating: -15 ~ 50℃ (5 ~ 122℉), Storage: -30 ~ 70℃ (-22 ~ 158℉) |
|---|
| Operating Humidity | Operating: 10 ~ 80% RH |
|---|
| Sealing | IP54 |
|---|
| Drop Rate | 2.1 m (7 ft.) |
|---|
| Emulation | BPL-C™ (CPCL), BPL-Z™ (ZPLII), SLCS™ |
|---|
| Driver / Utility | Bartender UL, Label Artist-II™, Linux / Mac CUPS Driver, OPOS / JPOS Driver, Utility Program, Virtual COM USB / Ethernet Driver, Windows Driver (Europlus / Seagull) |
|---|
| SDK / Plugin | Android / iOS / Windows SDK, Cordova Plugin, Linux SDK, Xamarin SDK |
|---|
| Application | Label Artist™ Mobile (Android, iOS), mPrint App (iOS), mPrint Server (Windows, iOS) |
|---|
| MDM | BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android) |
|---|
| • •Fonts/Graphics/Symbologies | • • • • • • • • • • |
|---|
| Fonts | 10 SLCS™, 16 BPL-Z™, 23 Code Page, 7 BPL-C™, One BPL-Z™, One SLCS™, Unicode supported (UTF-8, UTF-16LE,UTF-16BE) |
|---|
| Graphics | Supporting user-defined fonts, graphics, formats, and logos |
|---|
| Barcode Symbologies | • • • • • • • • • • |
|---|
| 1D | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar (RSS-14), IMB, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, Standard 2-of-5, UPC-A, UPC-E, UPC/EAN extensions |
|---|
| 2D | Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
|---|
| Standard Accessories | Battery Pack, Belt Strap, Paper Disk (Inner core : 12mm), Power Cord, SMPS |
|---|
| Optional Accessories | Fixed Serial / USB Cable, Quad Battery Charger, Serial / USB Cable, Shoulder Strap, Single Battery Charger |
|---|
| Supplies | B-linerlessTM : BIXOLON’s flexible and ecological linerless label consumables |
|---|
