On Count And Hands Free Scanner MP7000

Zebra Products In Qatar

Deliver a superior checkout experience for cashiers and shoppers in high volume POS lanes with the MP7000. This next generation multi-plane 1D/2D imager is loaded with features that take scanning performance and simplicity to the next level for faster-than-ever checkout in cashier-manned and self-checkout lanes. With the optional color camera, you can develop exciting new applications, such as identifying and recognizing produce for faster checkouts and preventing barcode switching and other risks in self-checkout. A smart investment, the MP7000 offers an unmatched industry-best total cost of ownership (TCO) by delivering maximum uptime and minimum power consumption in an easy-to-service design with fewer parts and components. And with Zebra’s complimentary powerful management applications, you can remotely manage all of your MP7000s, no matter where they are located.

Deliver a superior checkout experience for cashiers and shoppers in high volume POS lanes with the MP7000. This next generation multi-plane 1D/2D imager is loaded with features that take scanning performance and simplicity to the next level for faster-than-ever checkout in cashier-manned and self-checkout lanes. With the optional color camera, you can develop exciting new applications, such as identifying and recognizing produce for faster checkouts and preventing barcode switching and other risks in self-checkout. A smart investment, the MP7000 offers an unmatched industry-best total cost of ownership (TCO) by delivering maximum uptime and minimum power consumption in an easy-to-service design with fewer parts and components. And with Zebra’s complimentary powerful management applications, you can remotely manage all of your MP7000s, no matter where they are located.



Dimensions

Long scanner and scanner/scale: 20 in. L x 11.5 in. W x 4.00 in. D x 5.00 in. H 506 mm L x 292 mm W x 102 mm D x 128 mm H, Medium scanner and scanner/scale: 15.7 in. L x 11.5 in. W x 4.00 in. D x 5.00 in. H 398 mm L x 292 mm W x 102 mm D x 128 mm H, Short scanner: 13.9 in. L x 11.5 in. W x 4.00 in. D x 5.00 in. H 351 mm L x 292 mm W x 102 mm D x 128 mm H

Weight

Long scanner: 14.6 lb/6.6 kg, Long scanner/scale: 17.6 lb/8.0 kg, Medium scanner: 12.6lb / 5.7 kg, Medium scanner/scale: 15.7 lb/ 7.1 kg, Short scanner: 12.1 lb/ 5.5 kg

Scale

30 lb. in 0.01 lb. increments/15 kg in 5 g increments, Compatible with Mettler price computational scales Options: 0-12 lb. in 0.005 lb. increments and 12-30 lb. in 0.01 lb. increments 0-6 kg in 2 g increments and 6-15 kg in 5 g increments, Maximum static weight: 300 lb./136 kg, Single-cable and dual-cable protocols, Single-head and dual-head remote scale displays

Horizontal Glass

Sapphire; produce flip-up bar on scale models

User Interface

Beeper: adjustable volume and beep tones, Four programmable buttons, Large two-color LED, Soft touch capacitive pads (no buttons to break or wear out)

Ports

Checkpoint interlock port, One shared POS port for USB/RS-232/IBM RS-485, Remote scale display port, Three USB peripheral ports, Two powered RS-232 peripheral ports

Power

12VDC from POS interface cable (USB PlusPower or RS-232), Power consumption: Idle mode: 3.0 W (typical) Active mode: 5.5 W (typical), 6.0 W (maximum, only when illumination is on), Zebra PWR-BGA12V50W0WW power supply: 90V – 264V (110-240 nominal), 47-63Hz (50-60 nominal)

Operating Temperature

32° F to 104° F/0° C to 40° C

Storage temperature

-40° F to 158° F/-40° C to 70° C

Humidity

20 to 95% non-condensing

• • Imaging Characteristics

• • • • • • • • • •

Imaging Type

Multiple CMOS Array Imager

Illumination

Intelligent Illumination, controlled by item detection system

Sides Read/Scan Zone

Reading of linear and 2D codes in all planes

1D

2 of 5 (Interleaved, Discrete, IATA, Chinese), 2-digit Supplementals, 5-digit Supplemental, Bookland EAN, Codabar, Code 128, Code 39 (standard, full ASCII), Code 93, EAN-13, EAN-8, EAN128, GS1 DataBar (Omnidirectional, Truncated, Stacked), GS1 DataBar Expanded (regular, stacked), GS1 DataBar Expanded coupon, GS1 DataBar Limited, JAN 8, JAN-13, MSI/Plessey, Pharmacode (Code 32), TLC-39, Trioptic Code 39, UPC-A, UPC-E, UPC-E1

2D

Aztec, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR code

Digimarc

Digimarc barcode

UTILITIES AND MANAGEMENT

123Scan, Loss Prevention, Scanner Management Service (SMS), Symbol Scanner SDK
