TC15 MOBILE COMPUTER


The TC15 mobile computer is designed to meet the demands of today’s fast-paced on-demand economy. With a rugged build, large 6.5-inch display, enterprise-grade scanning, and all-day battery life, it empowers workers across logistics, transportation, and retail to complete tasks faster and more accurately—both indoors and in the field.

The on-demand economy is driving an ever-growing volume of orders that require rapid delivery, often on the same day. To keep up, workers across the supply chain must have quick and easy access to critical information — no matter the environment or job type. The TC15 mobile computer is purpose-built to address these challenges with unmatched versatility, power, and durability.

Featuring a rugged design that is waterproof, dustproof, and drop-resistant, the TC15 stands up to harsh conditions from warehouses to outdoor fieldwork. Its large 6.5-inch display offers a crystal-clear view of more data with less scrolling, optimized for use even in bright sunlight or wet conditions — gloves included. Thanks to an ergonomic design crafted by Zebra’s award-winning Industrial Design team, the device is comfortable to hold and easy to operate throughout long shifts.

Powered by a Qualcomm octa-core 2.2 GHz processor and a removable 5000 mAh battery, the TC15 supports multiple demanding applications simultaneously and delivers full-shift battery life with fast charging capabilities. Connectivity is seamless with support for 5G, dual SIM slots, Wi-Fi 6, Bluetooth 5.1, and NFC, ensuring workers stay connected wherever they are.

Equipped with an omni-directional enterprise-grade scanner, the TC15 captures virtually any barcode instantly—even damaged or dirty ones—and supports advanced scanning features including image capture and OCR for a wide range of industries. A 13 MP rear camera allows workers to document deliveries, inspect products, or conduct visual audits with ease.

Business-class accessories like charging cradles, hand straps, and rugged boots enhance device management and protection, while Zebra’s Mobility DNA tools enable easy integration, enhanced security, and efficient device deployment.

Physical Characteristics

Dimensions 6.92 in. L x 3.09 in. H x 0.56 in. D
175.8 mm L x 78.6 mm W x 14.2 mm D
Weight 9.38 oz/266 g
Display 6.5 inch/16.51 cm HD+, 720 x 1600, 450 NITS
Touch Panel Capacitive multi-touch
Power Removable, rechargeable Li-Ion battery, 5,000 mAh; 19.35Wh
SIM Dual nano SIM or One NANO one Micro SD
Network
Connections
WLAN, WWAN, WPAN, Type C USB 2.0
Notifications Audible tone; multi-color LEDs; vibration
Keypad On-screen touch keypad
Voice and Audio Speaker 1 Watt
Two (2) microphones
Audio headset supported from USB-C port or
Bluetooth
Buttons Scan button on each side; volume up/down button; power button; Programmable button

Performance Characteristics

CPU Qualcomm Snapdragon™ SM6375
Octa- (8) Core 2.2 GHz (2) & 1.8 GHz (6)
Operating System Upgradeable to Android 13
Memory 4 GB RAM/64 GB Flash
Security Verified boot, secure boot

User Environment

Operating Temp. 14°F to 122°F/-10°C to 50°C
Storage Temp. -40°F to 158°F/-40°C to 70°C
Humidity 5% to 95% non-condensing
Drop Specifications 4 ft./1.2 m drop to concrete per MIL-STD 810G across operating temperature
5 ft./ 1.5 m drop to concrete per MIL-STD 810G across operating temperature with rugged boot
Tumble
Specification
1,000 tumbles, 1.6 ft./0.5 m
Sealing IP65 and IP67
Vibration Sine: 4 g’s peak, 5 Hz to 2 kHz, 1 hour duration per axis
Random: 0.04 g²/Hz or 6 g RMS, 20 Hz to 2 kHz
Electrostatic
Discharge (ESD)
+/-15 kV air discharge, +/- 8 kV direct discharge;
+/- 8 kV indirect discharge

Interactive Sensor Technology (IST)

Light Sensor Automatically adjusts display brightness, display backlight
Motion Sensor 3-axis gyroscope; 3-axis accelerometer
Proximity Sensor Automatically detects when the user places the
handset against head during a phone call to
disable display output and touch input

Data Capture

Scanning SE4100 1D/2D Scan Engine, SE4710 1D/2D Scan Engine3
Camera Rear camera: 13 MP auto-focus camera with user controllable LED flash
Front camera: 5 MP
NFC Reader/Writer: ISO 14443 Type A and B, MIFARE, FeliCa®, ISO 15693, NFC Forum Tag Types 1 to 5; Host Card Emulation, NFC Forum compliant

Wireless WAN Data

Radio Frequency Band Support for 3GPP Rel-15,SA&NSA,4×4
MIMO,NRCA,DLCA
5G FR1: n1/2/3/5/7/8/20/28/38/40/41/66/77/78
LTE: B1/2/3/4/5/7/8/20/28/B38/39/40/41/42/43
UMTS: B1/2/4/5/8
GSM: 850/900/1800/1900
GPS GPS with A-GPS; Glonass; BeiDou; Galileo

Wireless LAN

Radio Wi-Fi 5
802.11a/b/g/n/ac/d/h/i/r/w/k IPv4, IPv6
Data Rates 2.4 GHz: 802.11b/g/n — 20 MHz, 40 MHz — up to 150 Mbps
5 GHz: 802.11a/g/n/ac – 20 MHz, 40 MHz, 80 MHz – up to 433 Mbps
Operating Channels Bands Of Operation: 2.4 GHz:
2.4 GHz to 2.497 GHz channels 1-13
Band of operation 5 GHz:
20 MHz channels:
5.15 GHz — 5.25 GHz (channels 36-48)
5.25 GHz — 5.35 GHz (channels 52-64)
5.470 GHz — 5.725 GHz (channels 100-140,144)
5.725 GHz — 5.825 GHz (channels 149-161)
5.825 GHz — 5.850 GHz (channel 165)
40 MHz channels (38, 46, 54, 62, 102, 110, 118, 126, 134, 142, 151, 159)
80 MHz channels (42, 58, 106, 122, 138, 155)
Actual operating channels/frequencies and
bandwidths depend on regulatory rules and
certification agency
Security and
Encryption
WEP Encryption
WPA-Personal and WPA-Enterprise security modes with TKIP encryption
WPA2-Personal and WPA2-Enterprise security modes with TKIP and AES encryptions.
WPA3-Personal and WPA3-Enterprise security; EAP-TTLS (PAP, MSCHAP, MSCHAPv2); PEAPv0-MSCHAPv2; PEAPv1-EAP-GTC; EAP-TLS
Fast Roam 802.11r (Over-The-Air)
Certifications WFA 802.11ac; WFA 802.11n; WFA WMM; WFA WPA and WPA2 certification in Personal & Enterprise modes; WFA WPA3; WFA Wi-Fi Direct

Wireless PAN

Bluetooth
Bluetooth 5.1 BLE, Class 2

Warranty

Subject to the terms of Zebra’s hardware warranty statement, the TC15 is warranted against defects in workmanship and materials for a period of one (1) year from the date of shipment. For complete warranty statement, please visit
www.zebra.com/warranty

Environmental Compliance

RoHS Directive 2011/65/EU; Amendment 2015/863; REACH SVHC 1907/2006
For a complete list of product and materials compliance, please visit
www.zebra.com/environment

Recommended Services

Protect your TC15 mobile devices with Zebra OneCare™ SV, the right-priced service for Zebra’s right-priced mobile devices. You get two years of protection against failure, coverage for normal wear and tear, live and online technical support, priority repair turnaround time and free shipping, as well as cloud-based visibility into reports on your devices — including repairs, tech support cases, contracts, LifeGuard Analytics for Android security patch status, and more. For more information on recommended services, please visit
www.zebra.com/zebraonecare

Regulatory

For Regulatory information, please visit
www.zebra.com/tc15

Footnotes

1. Enterprise Mobility Total Cost of Ownership: from the Expected to the Unexpected — Uncovering the True Costs of Mobile Solutions for Frontline Mobile Workers, VDC Research Group, October 2020
2. Future upgrades and updates will not support additional Wi-Fi 6 functionality
3. Scan engine availability varies by country
4. Requires sideloading
