POS Box TX-4700

POSIFLEX PRODUCTS

The TX-4700 is a fanless POS BOX running on Intel Bay Trail J1900 CPU, which is specifically designed to operate in all kinds of harsh environments. It offers a vast range of I/O connectivity options to connect POS peripherals, representing one of the most versatile POS BOX in the market.

The TX-4700 is a fanless POS BOX running on Intel Bay Trail J1900 CPU, which is specifically designed to operate in all kinds of harsh environments. It offers a vast range of I/O connectivity options to connect POS peripherals, representing one of the most versatile POS BOX in the market.



• • SPECIFICATION

• • • • • • • • • •

Processor

Intel Bay Trail J1900 Quad Core CPU, up to 2.42GHz, 2M Cache

System Memory

1 x DDR3L SO-DRIMM, max 8 GB

Storage Device

SATA Storage x 2

Power Supply

12V/60W

OS Support

Linux per request, POSReady 7, WE 8.1 Industry, Win 10 IoT, Win 7

SERIAL PORT

6, DB9 x 4, COM5/COM6 via optional cable from service window, 5V/12V support on all COM ports

PARALLEL PORT

1

STANDARD USB PORT

USB 2.0 x 7

POWERED USB PORT

Optional 24V x 1 + 12V x 1

LAN PORT

10/100/1000 Mb x 1

DISPLAY PORT

VGA x 1, 12V support for Posiflex monitors; optional 2nd VGA

CR PORT

1, control 2 CR via optional Y-cable

PS/2 PORT

Yes

Audio

Internal 2W speaker x 1 + Line-out

EXPANSION SLOT

M.2 x 1 + PCI x 1 (PCI to PCI-E riser card)

• • BUILT-IN OPTIONS

• • • • • • • • • •

WIFI

M.2 WiFi/BT module

• • PHYSICAL DIMENSION

• • • • • • • • • •

DIMENSION (W X D X H IN MM)

220 x 201.8 x 92

Weight

1.45

• • ENVIRONMENTAL

• • • • • • • • • •

OPERATING CONDITION

0°C – 40 °C, 20%RH – 90%RH (Equipped with HDD), 0°C – 50°C, 20%RH – 90%RH (Equipped with SSD)

STORAGE CONDITION

-20°C – 70°C, 10%RH – 90%RH
