Barcode Scanner MS-5145R

Posiflex Products

The MS-5145R Series is 1D laser barcode scanner with excellent and reliable reading performance. It has a longer working range and a wider scan field than a typical CCD. The width of the scan line grows as the scanner moves further away from bar codes.

The MS-5145R Series is 1D laser barcode scanner with excellent and reliable reading performance. It has a longer working range and a wider scan field than a typical CCD. The width of the scan line grows as the scanner moves further away from bar codes.



• • SPECIFICATION

• • • • • • • • • •

Form Factor

Handheld 1D Laser Scanner

Light Source

Visible Laser Diode (VLD) @ 650 nm

RESOLUTION

0.102 mm/4 mil

Depth of Field

0 mm – 140 mm (0" – 5.5"), 0.33 mm/13 mil Bar Code

Scan Method

Single scan line

Scan Angle

50°

Scan Rate

72 scans/sec

Decode Capability

Standard 1D and GS1 DataBar symbologies

Interface

Serial (MS-5145R)

DIMENSION (W X D X H IN MM)

63 x 169 x 51

WEIGHT (N. W. IN KG)

100

BRAND
