General Purpose Gun Type Scanners IG620BT


IG620/IG620BT is a brand new general purpose handheld area imager barcode scanner which is designed especially for retail, logistic market. We include friendly functions with replaceable multiple interface cable options that makes it more easily to be operated by customers to accommodate it to user environments.

IG620/IG620BT is a brand new general purpose handheld area imager barcode scanner which is designed especially for retail, logistic market. We include friendly functions with replaceable multiple interface cable options that makes it more easily to be operated by customers to accommodate it to user environments.



• • ENVIRONMENTAL

• • • • • • • • • •

Operating Temperature

0°C to 50°C (32°F to 122°F)

Storage temperature

-20°C to 70°C (-4°F to 158°F)

Ambient light

up to 100,000 Lux

• • SPECIFICATION

• • • • • • • • • •

Dimensions (WxDxH)

71.13 mm(W) X 62.61 mm(H) X 169.27 mm(L)

Light Source

Visible Red light 635±5nm LED

Filed of View

Horizontal: 40°, Vertical: 25°

Depth of Field

PCS90%, Up to 300mm@20mil/0.5mm

RESOLUTION

1D: 4mil/0.1mm, 2D: 10mil/0.26mm

Scan Rate

60 images per second

Indicators

Beeper and LED

Drop resistance

1.2m (wireless model), 1.5m (wired model)

Print Contrast Ratio

PCS45%@5mil/0.127mm

Wireless Standard

Bluetooth V2.1, HID and SPP profile supported

Battery

Lithium-ion Battery (3.7V, 2600mAh)

Recharge Time

Approx. 5 hours

Scan Per Charge

20,000 times in continuous read

Radio Transmission Range

Class 1, up to 100m (in open space)

Interface

KBW, RS232, USB (HID, Virtual COM)

Power

DC 5V
