Impact POS Printer SRP-275III

Bixolon Products in Qatar

A high quality and reliable Dot-Matrix Receipt printer, the SRP-275III featuring an ergonomic easy clean design and paper loading making it the ideal solution for any Hospitality Kitchen, Front of House or Retail printing situation. Producing high quality two colour printing even in the harshest of environments at speeds up to 5.1lps (at 40 columns). Equipped with Intelligent Logic Seeking and Bi-Directional Print Technology, this fast and quiet printer has the ability to print multiple copies of the same data with a reliability of up to 18 million lines. Featuring an optional Tear-Bar or Auto Cutter, the SRP-275III boasts three interface options including USB V2.0 FS + Serial + Ethernet*, USB V2.0 FS + Parallel or USB V2.0 FS + Serial (*DHCP enabled).

A high quality and reliable Dot-Matrix Receipt printer, the SRP-275III featuring an ergonomic easy clean design and paper loading making it the ideal solution for any Hospitality Kitchen, Front of House or Retail printing situation. Producing high quality two colour printing even in the harshest of environments at speeds up to 5.1lps (at 40 columns). Equipped with Intelligent Logic Seeking and Bi-Directional Print Technology, this fast and quiet printer has the ability to print multiple copies of the same data with a reliability of up to 18 million lines. Featuring an optional Tear-Bar or Auto Cutter, the SRP-275III boasts three interface options including USB V2.0 FS + Serial + Ethernet*, USB V2.0 FS + Parallel or USB V2.0 FS + Serial (*DHCP enabled).



• • SPECIFICATION

• • • • • • • • • •

Print Method

9 Pin, Serial Dot Matrix

Print Speed

Up to 5.1 lps (at 40 colums)

PRINT RESOLUTION

144 dpi (Vertical), 80 dpi (Horizontal)

PRINT WIDTH

Up to 63.5 mm

SENSOR

Black Mark, Paper End, Paper Near End, Rear Cover Open, Wall Mounting Paper Near End

Media Type

Receipt

Media Width

76.5 mm

Media Roll Size

Up to 83 mm

Media Thickness

0.06 ~ 0.085 mm

Supply Method

Easy Paper Loading

DIMENSION (W X D X H IN MM)

160 x 239 x 157 mm

Weight

A: 2.4 kg (5.29 lbs.), C: 2.5 kg (5.51 lbs.)

Electrical

50/60Hz, EnergyStar Certified, External Power Supply Housed Internally (Adaptor 24V/2.5A)

Drawer Port

2 Ports (Via y-type adaptor)

NV Image Memory

256 Kbytes (Mono)

Receive Buffer

64 Kbytes

User Define Buffer

64 Kbytes

Interface

* DHCP enabled, ① USB V2.0 FS + Serial + Ethernet*, ② USB V2.0 FS + Parallel, ③ USB V2.0 FS + Serial

• • ENVIRONMENTAL

• • • • • • • • • •

Operating Temperature

Operating: 0 ~ 40℃ (32 ~ 104℉), Storage: -20 ~ 60℃ (-4 ~ 140℉)

Operating Humidity

Operating: 10 ~ 80% RH, Storage: 10 ~ 90% RH

Thermal Print Head (TPH)

300 Million Dots/Wire

Auto Cutter

1.5 Million Cuts

Emulation

BXL / POS

Driver / Utility

Linux / Mac CUPS Driver, OPOS / JPOS Driver, Utility Program, Virtual COM USB / Ethernet Driver, Windows Driver

SDK / Plugin

Android / iOS / Windows SDK, Chrome SDK, Linux SDK

Application

mPrint Server (Windows, iOS)

MDM

BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android)

• •Fonts/Graphics/Symbologies

• • • • • • • • • •

Character Size

CHN: 16 x 16, Font A: 9 x 9, Font B: 7 x 9, KOR: 17 x 9

Characters Per Line

CHN: 22, Font A: 35, Font B: 40, KOR: 20

Character Sets

Alphanumeric: 95, Extended Graphics:128 x 27 page, International: 48

Graphics

Supporting user-defined fonts, graphics, formats, and logos

Optional Accessories

B-Melodist, External buzzer, Ribbon Cartridge, Splash Proof Cover, USB A-B Cable 1.8m, Wall Mount
