STANDARD FEATURES | 5 status icon, 3 button user interface, Bluetooth low energy, Direct Thermal print method, Dual-wall frame construction, ENERGY STAR qualified, OpenACCESS™ for easy media loading, USB 2.0, USB Host, ZPL and EPL programming languages |
• • Physical Characteristics | • • • • • • • • • • |
Dimensions | 8.6 in. L x 4.5 in. W x 6.0 in. H |
Weight | 2.2 lbs./1.0 kg |
• • SPECIFICATION | • • • • • • • • • • |
RESOLUTION | 203 dpi/8 dots per mm, Optional 300 dpi/12 dots per mm |
Memory | 512 MB Flash; 256 MB SDRAM |
Maximum Print Width | 2.2 in./56 mm for 203 dpi and 300 dpi |
Maximum Print Speed | 4 in./102 mm per second (300 dpi), 6 in./152 mm per second (203 dpi) |
Media Sensors | Full width, moveable reflective/black mark sensor, multi-position transmissive/ gap sensor |
FIRMWARE | EPL 2, EPL Line Mode, XML, ZBI, ZPL II |
• • Media Characteristics | • • • • • • • • • • |
Maximum Label Length | 39.0 in./991 mm |
Maximum Label and Media Width | 2.36 in./60 mm |
Media Roll Size | 2.0 in., (50.8mm) and 3.0 in. (76.2mm) using optional adapters, 5.00 in./127 mm outer diameter, Core inner diameter: 0.5 in. (12.7mm) and 1.0 in. (25.4mm) standard, 1.5 in. (38.1) |
Media Thickness | 0.003 in. (0.08 mm) min. – 0.0075 (.1905mm) |
Media Type | , die-cut or ccontinuous direct thermal or thermal transfer labels with or without black line, continuous receipt paper, Roll-fed or fan-fed, tag stock, wristbands |
• • OPERATING CHARACTERISTICS | • • • • • • • • • • |
Operating Temperature | 40° to 105° F/4.4° to 41° C |
Storage temperature | -40° to 140° F/-40° to 60° C |
Operating Humidity | 10% to 90% non-condensing |
Electrical | 50/60Hz, Auto-detectable (PFC Compliant) 100-240VAC, ENERGY STAR qualified, optional 2750 mAh battery |
Storage Humidity | 5% to 95% non-condensing |
PRINTER SUPPLIES | Keep your Zebra printer up and running with genuine Zebra printer supplies, available directly from Zebra. |
Options and Accessories | • • • • • • • • • • |
Media Handling | Field installable dispenser — label peel and present with label present sensor; field installable cutter |
Communications | DB-9, Factory installed or field installable Ethernet — 10/100 internal, factory installed wireless dual radio: 802.11ac Wi-Fi and Bluetooth 4.1; Bluetooth Low Energy included as standard on network connected models, Field installable RS-232 auto-sensing Serial |
Battery | Provides power to the printer to support a full shift of printing at maximum print speed; supports all media handling options |
Healthcare Model | Healthcare model with IEC 60601-1 compliant power supply and healthcare wipeable plastics |
Real Time Clock | Real time clock included as standard on network connected models |
Keyboard Display Unit | ZKDU keyboard display units for stand-alone printing solutions |
Mounting Plate | Optional accessory to secure ZD Series printers to countertops or shelves |
• •Fonts/Graphics/Symbologies | • • • • • • • • • • |
Barcode Ratios | 2:1 and 3:1 |
1D | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2 of 5, ISBT-128, Logmars, MSI, Planet Code, Plessey, Postnet, Standard 2-of-5, UPC and EAN 2-or 5-digit extensions, UPC-A, UPC-E |
2D | Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code |
FONTS AND GRAPHICS | 16 resident expandable ZPL II bitmap fonts, 64 MB user available non-volatile memory, 8 MB user available SDRAM, China units include SimSun simplified Chinese font, Five resident expandable EPL2 fonts, native open-type font support, two resident scalable ZPL fonts, Unicode compliant |
BRAND | ZEBRA |
