JIVA XT 3815-G2


Powered by Intel processor Elkhart Lake, the XT-3815-G2 features a 15″ bezel-free true-flat PCAP touch screen, beautifully sculptured slim body, and sexily curved base stand, the XT-3815-G2 looks right at home at any elegantly decorated store. And more than just good looks, the XT-3815-G2 also offers ample performance and flexibility to satisfy the most demanding of daily POS operations.

Sleek Look

  • Slimmer than ever! Every curve and detail of the XT-3815-G2 is carefully thought out to make itself one of the most visually desirable terminals in the market.

Performance

  • The XT-3815-G2 is able to equipped with Intel Elkhart Lake processor that is powerful enough to process anything throws at it without even breaking a sweat.

Multi-Position Folding Base

  • The patented foldable base of the XT-3815-G2 enables users to adjust the screen to a height and angle of their choice, providing unparalleled flexibility. (U.S. Patent 9004436)

Fanless Design

  • Solve the fan maintenance issue and provide silent mode operation, which is ideally suited for high-end boutique stores or hospital environments.

GEN8E Base

  • Optional GEN8E Base (U.S. Patent 9004436) that integrates internal power adaptor and PoweredUSB port into the base stand, which keeps counters clutter-free.
System Configuration
Processor Intel Elkhart Lake Celeron J6412, up to 2.60 GHz, 1.5M Cache
System Memory DDR4 SO-DIMM x 2, max. 32GB
Storage Device M.2 connector [supporting AHCI mode] x 2
RAID Function N/A
Intel vPro Support N/A
TPM Support Yes, TPM 2.0
Power Supply 12V/60W
OS Support Windows 10 IoT 64 bit
Display & Touch
LCD 15″ TFT LCD
Resolution 1024 x 768
Touch True-flat PCAP touch with multi-touch support (IP65 on front panel)
I/O Expansion
Serial Port 6, DB9 x 3 + RJ50 x 1 + 2 via optional converter cable from service window, 5V support on all COM ports, 12V support on COM1 to COM 4 (all converter cables are optional)
Parallel Port 1, via optional conversion cable through service window
Standard USB Port 7, USB 3.0 x 3 + USB 2.0 x 4
PoweredUSB Port Optional 24V x 1 + 12V x 3 via GEN8E base
OTG USB
LAN Port 10/100/1000 Mb x 1
Display Port VGA x 1, 12V support for Posiflex monitors
CR Port 1, control 2 CR via optional Y-cable, supporting 24V cash drawer
PS/2 Port 1, via optional conversion cable through service window
UPS Port Yes, battery optional
Audio Internal 2W speaker x 1
Expansion Slot M.2 slot x 1
Physical Dimension
Dimension (W x D x H in mm) 372 x 320 x 252.7
Weight (N. W. in kg) 5.6
Environmental
Operating Condition 0°C – 50°C, 20%RH – 90%RH (Equipped with SSD)
Storage Condition -20°C – 70°C, 10%RH – 90%RH
Built-in Options
WiFi M.2 WiFi/BT module
Camera
MSR
AG Glass
Attachment Options
POS Monitor Non-touch TFT LCD: 7″/9.7″/12.1″/14″/15″;
PCAP touch TFT LCD: 9.7″/14″/15″;
Resistive touch TFT LCD: 15″
Line Display 2 x 20 rear-mount VFD/LCD customer line display; 7″ color LCD graphical customer line display
External UPS Pack For RT Series
Attachment MSR; iButton; Rotatable 2D Scanner; RFID; Fingerprint Sensor; Keypad
* The product information and specifications are subject to change without prior notice.
