| • • Physical Characteristics | • • • • • • • • • • |
|---|
| Dimensions | 171.7 mm H x 34.1 mm D x 60.9 mm W, 6.76 in. H x 1.34 in. D x 2.40 in. W |
|---|
| Weight | Batch with battery: 8.2 oz./231.7 g to 8.4 oz./237.7 g, WLAN with battery: 8.3 oz./234.7 g to 8.5 oz./240.7 g |
|---|
| Display | 2.8 in. QVGA with backlight; TFT-LCD, 64K colors |
|---|
| Touchpanel | Resistive touch panel (MC2180 only) |
|---|
| Keypad | 2 programmable side buttons (MC2180 only), 27-key numeric, supports keypad overlays for localization and custom functions |
|---|
| EXPANSION SLOT | User accessible Micro SDHC card slot (up to 32GB) |
|---|
| Connectivity | USB 1.1 full speed host/client, Wi-Fi 802.11b/g/n and Bluetooth (MC2180 only) |
|---|
| Notification | LED and audible alert |
|---|
| • • Performance Characteristics | • • • • • • • • • • |
|---|
| CPU | Marvell PXA 320 624 MHz |
|---|
| Operating System | Microsoft® Embedded CE 6.0 Core & Pro (MC2180 Only) Editions |
|---|
| Memory | 128 MB RAM/256 MB ROM, 256MB RAM/256MB ROM (MC2180 Only), user accessible microSD card slot (supports up to 32GB) |
|---|
| • • USER ENVIRONMENT | • • • • • • • • • • |
|---|
| Operating Temperature | 14° F to 122° F/-10° C to 50° C |
|---|
| Storage temperature | -40° F to 158° F/-40° C to 70° C |
|---|
| Humidity | 5% to 95% non-condensing |
|---|
| Sealing | IP54 |
|---|
| Vibration | 1 hour duration per axis, 2Gs peak, 5Hz to 2kHz |
|---|
| Drop Specification | 3 ft./0.91 m to concrete across operating temperature, 4 ft./1.2 m drops per MIL STD 810G, 4 ft./1.2 m to concrete at room temperature |
|---|
| Tumble Specification | tumbles (1,000 hits) @ 1.64 ft./0.5 m |
|---|
| Development Tools | Zebra Technologies RhoElements for cross platform applications; EMDK suite (C, .NET and Java) |
|---|
| Management Tools | Zebra’s Mobile Device Management (MDM) solutions |
|---|
| Electrostatic Discharge (ESD) | ±15kVdc air discharge, ±8kv contact discharge |
|---|
| • • POWER | • • • • • • • • • • |
|---|
| Battery | 2400 mAh rechargeable Smart Li-Ion; user replaceable |
|---|
| • • DATA CAPTURE | • • • • • • • • • • |
|---|
| Scanner Options | 1D linear imager, 1D(1) laser, 1D/2D area imager (MC2180 only) |
|---|
| Exit Window | Corning® Gorilla® Glass |
|---|
| • • WIRELESS COMMUNICATIONS | • • • • • • • • • • |
|---|
| WLAN¹ | 802.11b/g/n |
|---|
| WLAN Security | 802.1x, CCXv4 certified, EAP-FAST (TLS, MS-CHAPv2, EAP-GTC), EAP-TLS, LEAP, PEAP (TLS, MSCHAPv2, EAP-GTC), TLS,TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP or MD5), WEP, WPA, WPA2 |
|---|
| WPAN | Bluetooth Class II, integrated antenna, v 2.0 with EDR |
|---|
| • • Voice and Audio | Speaker and microphone (MC2180 only) Buzzer (MC2100 only) |
|---|
| Push-to-Talk | high quality speakerphone, PTT (client included), PTT will support headset and speakerphone mode (MC2180 Only), wired headset support |
|---|
| Voice Directed Picking | Compatible with 3rd party VDP clients (MC2180 only), PTT will support headset and speakerphone mode (MC2180 Only) |
|---|
| BRAND | ZEBRA |
|---|
