• • PHYSICAL CHARACTERISTICS | • • • • • • • • • • |
---|
Dimensions | 143.91 mm H x 72.8 mm W x 20.1 mm D, 5.66 in. H x 2.87 in. W x 0.79 in. D |
---|
Weight | 9.38 oz./266.1 g (with battery) |
---|
Display | 4.3 in. capacitive; 480 x 800; 300 NIT |
---|
Touchpanel | Capacitive dual-touch, Corning Gorilla Glass |
---|
Backlight | LED backlight |
---|
Power | PowerPrecision 2680 mAh Li-Ion rechargeable battery |
---|
Backup Battery | NiMH battery (rechargeable) 15 mAh 3.6 V (not user accessible) |
---|
Connectivity | USB 2.0 OTG connector |
---|
Notification | audio and vibration, LED |
---|
Keypad | On-screen keypad |
---|
Disinfectant Ready | Yes |
---|
• • Performance Characteristics | • • • • • • • • • • |
---|
CPU | 1 GHz OMAP 4 dual core processor |
---|
Operating System | Android 5.1 Lollipop with Zebra’s Mobility Extensions (Mx) |
---|
Memory | 1 GB RAM/8 GB pSLC Flash |
---|
• • USER ENVIRONMENT | • • • • • • • • • • |
---|
Operating Temperature | 0° C to 40° C / 32° F to 104° F |
---|
Storage temperature | -40° C to 70° C / -40° F to 158° F |
---|
Humidity | 5% to 85% RH non-condensing |
---|
Drop Specification | multiple 3 ft./0.9 m drops to tile, Multiple 4 ft./1.2 m drops per MIL-STD 810G |
---|
Tumble Specification | 500 1.6 ft/0.5 m tumbles, meets and exceeds IEC tumble specifications |
---|
Sealing | IP54 |
---|
Electrostatic Discharge (ESD) | ± 15kVdc air discharge, ± 2kVdc indirect dischar, 8kVdc direct discharge |
---|
Corning Gorilla Glass | camera exit window, scanner exit window, Touch panel |
---|
Audio | handset/speakerphone modes, High-quality speakerphone, PTT headset support, wireless (Bluetooth) headset support |
---|
• • INTERACTIVE SENSOR TECHNOLOGY | • • • • • • • • • • |
---|
Motion Sensor | 3-axis accelerometer provides motion-sensing for dynamic screen orientation and power management |
---|
Light Sensor | Automatically adjusts display backlight brightness |
---|
Proximity Sensor | Prevents unwanted key presses in handset mode |
---|
• • DATA CAPTURE | • • • • • • • • • • |
---|
Imager | SE4710 |
---|
CAMERA | Rear-facing 8 MP auto-focus with aiming for barcode scanning and image capture |
---|
• • WIRELESS LAN | • • • • • • • • • • |
---|
Radio | Tri-mode IEEE® 802.11a/b/g/n/d/h/i/k/r 4 |
---|
Security | Authentication: TLS, TTLS (MS-CHAP), TTLS (MS-CHAP v2), TTLS (PAP), PEAP (MS-CHAP v2), PEAP (GTC), FAST (MS-CHAP v2), FAST (GTC), LEAP, Data at Rest: FIPS 140-2 Level 1, Data in Motion: FIPS 140-2 Level 1, Encryption: WEP (40 and 128 bit), TKIP and AES, Security Modes: Legacy, WPA and WPA2 |
---|
Data Rates | 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps, 802.11b: 1, 2, 5.5, 11 Mbps, 802.11n with SGI: 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2 Mbps, 802.11n: 6.5, 13, 19.5, 26, 39, 52, 58.5, 65 Mbps |
---|
Fast Roam | 802.11r, Cisco CCKM, Opportunistic Key Caching (OKC), PMKID caching, Zebra Aggregated FT |
---|
Certifications | Chan 36-165 (5180 – 5825 MHz), Chan 1-13 (2412 – 2472 MHz); actual operating channels/frequencies depend on regulatory rules and certification agency |
---|
Operating Channels | Chan 36-165 (5180 – 5825 MHz), Chan 1-13 (2412 – 2472 MHz); actual operating channels/frequencies depend on regulatory rules and certification agency |
---|
• • WIRELESS PAN | • • • • • • • • • • |
---|
Bluetooth¹ | Bluetooth Class II, v 2.1 with EDR; Bluetooth 4.0 (Bluetooth Smart) |
---|
BRAND | ZEBRA |
---|
